XL461 is a semi-automatic sealing machines with random adjustment.
It means that these machines are able to adjust themselves on the different box dimensions. The machines are designed to apply automatically a “C” strip of adhesive tape of the top and bottom of boxes.
Machines adjustments and use are intuitive, simple and fast.
On the XL461 version the rest position of the top taping unit is UP: thanks to some particular devices the feeding of boxes is performed automatically.
Key Features ;
Automatic adjustment on different box sizes
Side lower drive belts (2 x 75 mm width each)
Drive belts speed 20 m/min.
2 x Motors kW 0,13 each
2 x K12R taping unit - 75 mm width
Extruded aluminium telescopic legs with millimetric guide
Locked stop emergency button
On/Off magneto-thermic switch
Adjustable descending height stopper of the top taping unit to increase speed rate
Top head pneumatic pressure regulators
Safety protections with switches to disconnect electric & pneumatic circuits if opened
Adjustable working height 445 - 705 mm
