Safety Gates Dealers in Cherlapalli, Hyderabad

We are also into design and manufacturing of Electromechanical Large Sliding Gates for Air force Runways. Recently we have received an order for design and supply of Electromechanical Motorized Steel Sliding Gate of size 50m(L) x 3mtrs(H).

Viswakirti Designed for positive control of material discharge from chutes , bins, hoppers. Self-cleaning gate is non-clogging, closes completely to prevent trickling. Available in manual, air or motor-operated models to fit square chutes. Rugged construction.

• MATERIAL - MAIN BODY: 1.5 mm 304 grade stainless steel
• MATERIAL - SWING ARM: Steel profile frame with 32 mm diameter
• TREATMENT - OTHER PARTS: All other parts are coated against corrosion
• DIMENSIONS (mm): 260 x 1050 x 1150 (WxLxH)
• SWING ARM LENGTH (mm): 900
• OPERATING VOLTAGE: 115-240 V AC / 24V DC - 50-60 Hz
• NOMINAL / MAX. CURRENT: 100 mA / 500 mA
• POWER CONSUMPTION: 30 W
• OPERATING TEMPERATURE: -20 0C / + 70 0C
• ACCESS CONTROL: Microprocessor based control for granting access Easy integration with all kind of access control equipment
• POSITION DETECTION: Position detection with two separate micro-switches at mechanics
• DIRECTIONAL MODE: One directional motorized operation
• ROTATION CONTROL: Motion start and stop are controlled by PWM microprocessor
• CAPACITY: Handling more than 30 passengers per minute
• DESIGN: Modular design providing ease of installation and part replacement
• INSTALLATION: Stainless steel modular installation platform/base
• OPERATION SAFETY: Electrical and mechanical safety for all component. To avoid injuries, all corners and sides are rounded
• ANTI PANIC FEATURE: In case of emergency, arm releases itself with excessive force, providing ease of evacuation
• ACCESSORIES: Button Control (standard) Remote Control Receiver and Transmitter (optional
• CERTIFICATION: ISO 9001:2008
• WARRANTY: 2 Years
