STATIC SERVO HYDRAULIC COMPRESSION TEST SYSTEMS
Get Price Quote
Features
Load capacities
Type A: 300kN, 600kN, 1000kN, 2000kN & 3000kN
Type B: 1000kN, 2000kN & 3000kN
Type C: 1000kN, 2000kN, 3000kN & 5000kN
2 or 4 column construction with excellent alignment and good shock absorption
Servo hydraulic driven piston to apply compressive loads
Testing speed range: 0.1 to 200 mm/min
Loading rates: 0.02% of FS/sec to 2% of FS/sec
Encoder based feed back for excellent position control
Position control resolution down to 0.01mm
Moog servo valives for high accuracy control
Piston strokes up to 130mm
Horizontal test space up to 600mm
Tension test space up to 1100mm
Compression test space up to 400mm
Compression platen diameter 300mm
Works out of 3Ø 440 VAC
32 bit Digital Signal Processor based controller
5kHz servo loop update rates
Uses Strain Gaged Load Cell for accurate load values
Load accuracy ± 0.5% of read out value down to 1/100th of full capacity
Speed accuracy± 0.5% of set speed
Position accuracy ± 0.5% of read out
Strain accuracy ± 0.5% of read out value down to 1/50th of travel range
0-1.0 KHz data acquisition rates
Applications
Compression testing of building materials
Concrete blocks
Concrete cubes
Concrete slabs
...more
