Electrosurgical Unit
Get Price Quote
Hf electrosurgical unit shall be used to execute monopolar and bipolar surgery in
many fields of application where high precision and reliability are essential
outputs of cut, coagulate and blend
maximum output 300 w for monopolar cut
activation :
double pedal switch which may be used for the monopolar and bipolar functions .
Hand-switch handle
bipolar electrode with pedal switch or with automatic startstop system ( for
coagulation only)
control
the unit shall stop automatically in case of internal error which shall be identified on
display and with audible alarm
memorization : user shall be able to use at least 4 working programs
safety :
neutral plate safety circuit shall control connections and contacts of neutral plate
with tissues:
defective contact shall be notified with visual alarm and immediate reducing of
power
output circuit : floating - protected against defibrillator interferences . Shall have hf
leakages less than 150ma through each electrode
power supply : 220vac, 50hz
cooling: convection without fan
accessories :
single-use two button handle , autoclavable
handle shall be provided with a 3 pins socket that shall fit majority of bipolar
electrosurgical units
operative foot-switch (usable as alternative to handle)
reusable neutral plate
kit of 10 short autoclavable electrodes
electrode wire - straight
electrode wire - angled 45°
electrode bend - 0 4 - straight
electrode bend - 0 8 - straight
electrode hook - angled 45°
electrode wire 1 mm.- angled 45°
electrode straight slip-knot - straight
electrode angled slip-knot - straight
electrode ball point - 0 3 mm. - angled 45°
electrode ball point - 0 3 mm. – straight
bipolar forceps : 6
forceps shall be provided with a standard european connection
straight forceps - 18 cm. (7")
...more
