Indore Machinery Makers Siyaganj, Indore, Madhya Pradesh

OPTIONAL ACCESSORIES: CUTTING CAPACITY 3mm to 30mm, SHEET FRONT FEEDING SYSTEM NC BACKGUAGE REAY SHEET SUPPORTS AUTOMATIC CONTROL SHREAING SHEET REAR STACKING SYSTEM"   OPTIONAL FOR EXTRA REQUIREMENTS CHOICE OF CNC CONTROLLERS FOR CONTROLLING FUNCTIONS LIKE NC BACKGAUGE, BLADE GAP, RAKE ANGLE, STROKE ALSO INTEGRATES THE MACHINE WITH AUTOMATED ACCESSORIES FOR SHEET FEEDING, GAUGING, CONVEYING-SEPARATING, TRACKING ETC

Pillar Drilling machine MODEL-20/200 Max Drilling CAPACITY (M.S): 20 Max Drilling CAPACITY (C.I): 20 Powe( HP): 1 Spindle Speed (MIN/MAX): 08 (80/3500)   STANDARD ACCESSORIES: MOTOR PULLY OPTIONAL ACCESSORIES MOTOR 1 H.P 3 PH 1440 RPM, V-BELT, STATER, DRILL CHUCK,  DRILL CHUCK ARBOUR, DRILL CHUCK SLEEVE

Number Of Flower : Pillar Type Drilling Machine

Availability : 100-1000kg

Condition : New

Driven Type : Electric

Country of Origin : India

Brand Name : IMM

Drilling Speed : 80/3500

ALL GEARED RADIAL DRILLING  MACHINE MODEL ERAA-60/1500 Max Drilling CAPACITY (M.S):60 Max Drilling CAPACITY (C.I): 70 Powe( HP): 5 H.P   Spindle Speed (MIN/MAX): 10 (30-1500)   STANDARD ACCESSORIES  MOTOR PULLY, ELECRIC MOTORS, STATER,   OPTIONAL ACCESSORIES  DRILL CHUCK, DRILL CHUCK ARBOUR, DRILL CHUCK SLEEV, DRILL VICE

MAIN SPINDLE DIMENSIONS STANDARD 38 MM     LENGTH OF BED : 1370 MM(4.5')  FLOOR SPACE : 1500 X 850 APROX CASE DIEMSION (MM) : 1700 X 900 X1350   ELECTRICALS: MOTOR 1 H.P /0.75 KW, 3 PHASE , 50HZ, 440V, 1440 RPM, WITH REVERSE –FORWARD SWITCH, V-BELT, ELECTRICAL WIRINGS AND FITTINGS STANDARD ACCESSORIES: FLAME HARDENED BED WAYS, CHUCK PLATE, DEAD CENTRE (2 NOS), TOOL POST KEY, SPINDLE SLEEV, MOTOR PULLY, THREAD DIAL INDICATOR, CHIP TRAY, CHANGE GEAR SET (FOR METRIC AND INCH BOTH) OPTIONAL ACCESSORIES: FACE PLATE, CARRIER PLATE, STEADY REST, FOLLOW REST, TAPER TURNING ATTACHMENT, MOTORISED COOLANT PUMP WITH TANK FITTINGS, REAR TOOL POST WITH EXTENDED CROSS SLIDE, NORTON GEAR BOX AND ELECTRICALS ( PANEL, PUSH BUTTON, WIRING, SWITCH, MOTOR, V-BELT AND FITTINGS), Electrical switch shaft and splash guard

Type : Light Duty Lathe Machine

Driven Type : Electric

Country of Origin : India
