CCTV Systems
Get Price Quote
1/2" Ultra Low Light, High Resolution Color Camera
1/2" Exview color CCD with 410K pixels
Removed noise & ghost images with SSNR
Day & Night with ICR (Infrared Cutfilter Removal)
High Res. of 530TV lines (Color), 570TV lines (B/W)
0.08 Lux at F1.2 (Normal color mode) 0.01 Lux at F1.2 (B/W)
Privacy image masking with free position: 4 zones
Motion Detection, WDR
RS-232C remote control
OSD (On Screen Display)
S/N ratio of 50dB
Dual voltage : 24VAC / 12VDC
MONITORS (SAM-14MV)
14" Color CCTV Monitor
High Performance Resolution
Automatic color switching system(NTSC/PAL)
Front Panel Control
Free Voltage (100 ~ 240 VAC), Y-C Signals
Builit-in Speaker
S-VHS Input for separate
WEB SERVER
4CH Web Server SWC-304
Real-Time MPEG-4 video compression
Max.30fps(VGA) / 120fps(CIF) image compression & transmission (VGA)
Bi-directional audio
High resolution image (720 x 480, etc)
Static / Dynamic IP support
Remote Pan / Tilt / Zoom control (RS-232, RS-422, RS-485)
TCP/IP, RTP, RTCP, ARP, etc protocol Self-contained FTP/HTTP server & E-mail sending
DDNS Support
PC viewer /Web based ActiveX viewer application support
Security functions: password based user authentication control message encryption
4 sensor input, 4 alarm output
4 channel motion detection
DIGITAL VIDEO RECORDER (SVR-1650)
16 channel Premium Stand Alone DVR
Design
Hand polished look in mirror finish black
Logical control button and jog-dial location
Image Capabilbity
True real-time(480 fps) video display/recording
MPEG-4 compression technology
High resolution image (720 X 480)
Multiple recording settings
User Convenience
Easy back-up with 3 USB ports and built-in DVD+RW
Various input controllers including mouse, remote control and keyboard
User-friendly GUI menu, OSD(Multi-language)
Front USB 2 port and AV output port
Network Capability
Real-time video network transmission
Optimal and stable network speed
Integrated network multi-view, multi-users remote viewing
Manages up to 5 DVR simultaneously
Scalability
Large data backup using DVD+RW
250GB HDD internal capacity / 4 HDD bay external capacity
ATM/POS transaction data recording and search
Supports system control of up to 255 DVR and ptz dome
Audio 4 in/2 out, Sensor port 16 in/4 out
CONTROLLERS
System Controller
Capable of Controlling of PTZ dome cameras, DVRs and matrix switchers
Centralized Control of up to 255 Units from a Single Controller
Configurable to Connect Multiple System controllers up to 16 Units
Ergonomic Design and Easy-to-Use Keypad
3D Joystick Control of PTZ Functions
Backlit, Large Character LCD Display: 20 x 4 lines
Multi-Protocol Support
Preset positions : Max. 64 locations
Control of group sequence, tour sequence, PTZ trace function
Auto swing, Pan / Tilt swing control
...more
