Automatic Pet Preform Stretch Blow Moulding Machine
Get Price Quote
Automatic PET Preform Stretch Blow Moulding Machine is made using by the latest facilities and under the guidance of experts. Our Automatic PET Preform Stretch Blow Moulding Machine is known for its high performance and flawless design structure. Thus, we are reckoned as a trusted Manufacturer, Exporter and Supplier of Automatic PET Preform Stretch Blow Moulding Machine in Rajasthan.
Description
All the movement by linear rails to avoid friction and allow smooth operation thus saves energyPreforms are loaded automatically in open mould conditionBottles are ejected form mould with the help of auto AirBlowing air is supplied through valve block for fast and uniform distribution in mould cavitySafety guards are provided at preform loading and bottles ejection sectionSeparate air receiver for low pressure and high pressure provided inside the machine for uniform air supplyAir recovery valve is provided so that used blown air for the mould can be recollected and used again for low pressure application, thus saves energy. (Optional)The machine is controlled by PLC system for easy, accurate, fast & trouble free operation.Centralized lubrication system for all lubricating points. (Optional)Machine is mounted on anti- vibration mounting pad. (Optional)Air regulatory valve are provided to control air pressureVariable speed drive to vary the conveyer speed as per requirement.Infrared heaters are adjustable as per the preform shape & size.Separate motor for preform rotation.Quick changeable preform holder for jars and bottles.Preforms holders made from special Aluminium.Individual temperature controller for each infrared tube and are controlled by SSR (Solid state relay).
SpecificationsModelTK- 01TK- 02TK- 03TK- 04Product Size 30-500ML 200-1000ML 1000-2000ML 500-1000ML Product Output 185OBottHR 1000 BottHR 900 BottHR 1800BottlesHR Mould Cavity 2 Cavity 1 Cavity 1 Cavity 2 Cavity Neck Dia 25-28MM 28MM 28MM 28MM Heater Type IR IR IR IR Heater Power 10 KW 12 KW 18 KW 12 KW Clamping Stroke 150 MM 150 MM 200 MM 150 MM Blowing Preassure 15 KG 18 KG 20 KG 20 KG Operation Hydro-Penu Hydro-Penu Hydro-Penu Hydro-PenuRequared Exacessory Compressure HP 20 HPLP 15 HP HP 15 HPLP 10 HP HP 20 HPLP 15 HP HP 20 HPLP 15 HP Chiller 2 TR 2 TR 2 TR 2 TRNote : Air Dryer Requared as Applicable
