SizeOverall height of 2400 mm or 1800mm X 150 mm Width X 150 mm Breadth
FEATURES & SPECIFICATION
Each road indicator consists of two columns of overall height of 2400 mm or 1800mm X 150 mm Width X 150 mm Breadth, and one slab of 1740 mm Length X 900 mm Height X 40 mm Thickness
Manufactured by M-30 grade of concrete by vibro compaction process using FRP moulds, so as to achieve shuttering finishSuitably reinforced to prevent damage during handling, transportation and erection and to promote long use
Installation: Dig two holes of 500mm X 500mm X 600 mm depth @ at c/c distance of 1.6 meters, level and compact the bottom surface of the holes, insert and align the poles, and fill the gap with lean concrete
