Superstrate3.2 mm (0.13 inches) high transmission low iron tempered glass, AR coated
Cells72, 5BB Monocrystalline solar cells
Cell EncapsulantEVA (Ethylene Vinyl Acetate)
Back SheetComposite film
FrameAnodized aluminium frame with twin wall profile
Mechanical Load Test5400 Pa (Snow load), 2400 Pa (Wind load)
Maximum Series Fuse Rating15 A
Features
Efficiency up to 19.07%
Range- 340-370W
Extremely Narrow Power Binning Tolerance of +2.5 Wp to reduce current mismatch loss in single string
Using highly efficient Passivated Emitter Rear Contact Technology (PERC) cells resulting in Excellence Low Light and Longer Wavelength Response
10% Higher Power Output compared to industry average poly crystalline module
Extremely Reliable Product suiting harsh environment conditions withstanding 2400Pa Wind load, 5400Pa Snow load and Dynamic Wind load
Certified Salt mist and Ammonia resistance
Certified for PID resistance
Length × Width × Height : 1956 × 992 × 36 mm (77.01 × 39.06 × 1.42 inches)
10 Years of Product Warranty and 27 Years of Linear Performance Warranty
Applications
On-grid large scale utility systems
On-grid rooftop commercial and residential systems
Off-grid residential systems
Caution : Read Safety And Installation Manual Before Using The Product.
Specifications included in this datasheet are subject to change without notice. Electrical data without guarantee. Please confirm your exact requirement with the company representative while placing your order.
