Head Range42-250 mtr in 1 Phase
42-350 mtr in 3 Phase
Outlet size25,32,40 & 50 mm
Degree of ProtectionIP 68
Maximum Outer diameter98 mm
DutyS1 (Continuous)
Method of startingCapacitor star and capacitor run
(CSCR) in water filled Capacitor start and run (CSR) in oil filled In 1 Phase / DOL in 3 Phase
MountingAs per Nema
Material of Construction PumpNRV Housing
Stainless SteelCheck Valve
Stainless SteelCheck Valve sheet
NBRImpeller
Stainless SteelPump Shaft
Stainless SteelPump Shaft
SS - 431Suction inter Connector
Stainless SteelCoupling
SS 410Material of Construction Motor
Upper, Lower Housing & Motor BaseCast Iron (Regular) / Stainless Steel
Stator BodyCast Iron
ShaftStainless Steel
BearingLeaded Bronze in water filled Anti frictional deep groove ball bearing in oil filled
Thrust Bearing SetCarbon V/s SS in water filled
OSWAL submersible pumps & motors are well known for its quality, Reliability & excellence for all type of service purpose. OSWAL submersible pumps & motors are manufactured under supervision of highly qualified technical team with a stage wise rigid inspection procedure under TQM concepts.Application of Bore well submersible pumps are in Hospitals, Water circulation systems, Water supply systems of Government, Irrigation, Farms & Drip & sprinkler irrigation, Gardening, Nurseries, Domestic water supply, Multi-storey Building, Industries & Hotels.Manufactured by stainless steel fabricated technology, pumps are energy efficient and cost efficient, light weight easy for handling, life longevity, corrosion free. Pump shaft using Duplex steel for high wear resistance. Fully fabricated S.S.-304 pump set is with quality level as per international standard and the same quality is supply in domestic market.OSWAL Submesible Pumpsets of modular design is suitable for under-water operation for universal fit, all mounting dimensions of pumps and motors are in accordance with NEMA standards.OSWAL Oil Filled pumps sets are highly efficient, low power consumption, complete absence of suction trouble. Maintenance free operation due to water lubricating bearings, vibration free & noiseless operation and world class design gives higher discharge & high efficiency. Easily repairable & dismountable. OSWAL Oil Filled submersible motors are easily rewind able & repairable. Motor filled with food grade cooling oil. Oil filled motor consist of ball bearing to minimize the frictional losses & to increase the efficiency. Oil used as a coolant and work as lubricant in motor so life of motor is increases due to less wear & tear. The basic function of coolant is to lubricant bearing of rotor, removing heat generated in motor and oil is working as a coolant for smooth operation of pump. OSWAL BORE WELL SUBMERSIBLE PUMP confirm to IS : 8034.Mounting dimension of 4†pumps sets are as per NEMA standard
Application in : • Water supply from bore well• AC and solar energy compatible• Municipal & Irrigation purpose• Water supply in commercial establishments • Small farms, gardening & nurseries.
Application of Bore well submersible pumps are in Hospitals, Water circulation systems, Water supply systems of Government, Irrigation, Farms & Drip & sprinkler irrigation, Gardening, Nurseries, Domestic water supply, Multi-storey Building, Industries & Hotels. Manufactured by stainless steel fabricated technology, pumps are energy efficient and cost efficient, light weight easy for handling, life longevity, corrosion free. Pump shaft using Duplex steel for high wear resistance. Fully fabricated S.S.-304 pump set is with quality level as per international standard and the same quality is supply in domestic market. OSWAL Submesible Pumpsets of modular design is suitable for under-water operation for universal fit, all mounting dimensions of pumps and motors are in accordance with NEMA standards. OSWAL Oil Filled pumps sets are highly efficient, low power consumption, complete absence of suction trouble. Maintenance free operation due to water lubricating bearings, vibration free & noiseless operation and world class design gives higher discharge & high efficiency. Easily repairable & dismountable. OSWAL Oil Filled submersible motors are easily rewind able & repairable.
