Bottle Size20-70mm Ø X 40 – 250mm H X Neck 21 Ø - 25 Ø
Working Height850±50mm
Power Consumption5.0 KW
I/P Power Req.3 Phase/440V AC/50HZ
Air Supply2 – 4 kg/cm2 (If Required)
Rotary DirectionClockwise
Tank Capacity75 Liter
Application : Washing pet/glass bottle for pharmaceuticals, Food & beverages industry.Salient Features :
This is compact & versatile GMP Model.
Specially designed Geneva based mechanism for rotary start/stop operation.
High capacity centrifugal pump to wash bottle.
Specially designed bottle cup for easily loading/unloading bottle.
Individual control valve for wash pressure setting.
Separate SS 304 operating panel.
Wash the bottle in one external wash & four internal wash.
Separate pump & motor for easily clean & maintenance.
