Type of Transducer/ ProbeLinear Array, Convex, Phased Array, TVS
Doppler ModeColor Doppler Velocity, Pulse Wave, Continuous Wave, Power
Monitor Size21.5 iNCH
On PlatformBuilt-in
Battery BackupYes
Frequency50/60 Hz
SCANNING MODE
B-mode
M-mode
Anatomic M Mode 3 Lines
Free angular M mode .
TGC & LGC
Color Doppler &Power Doppler Imaging/ with Adaptive Doppler Imaging
Trapezoidal Imaging
Power Doppler Imaging .
Directional PDI
Digital pan ZOOM
Acoustic spot zoom .
Auto trace .
Dedicated Steer Control
Special Compound Imaging (SCI)
Auto IMT
Auto NT.
eVol. Flow
eOB.
eFollicle.
eLV.
Pulsed Wave Doppler
Continuous Wave Doppler (CW Doppler)
HPRF(High Pulse Repetition Frequency)
Static 3D / 4D Package
TDI(including Color-TDI and PW-TDI)
Auto Optimization of B mode .Color mode, PWD mode .
Needle enhancement visualization .
Panoroma Imaging .
Elastrography mode .
Contrast imaging .
AUTO OB ( BPD.HC,FL,HUM)
5-Active Transducer Ports
Battery Back-Up– Rechargeable Li-Ion Battery with Level Display in Main Screen and Charging Indicator
Removable GEL Warmer optional*
Built In DVD Drive optional*
WIFI Module
USB 3.0 (One )& USB 2.0(Six)
HDMI & Ethernet
DICOM Standard
AI TECHNOLOGY
Systems have Artificial Intelligence.
MONITOR
21.5’’ high resolution TFT LCD monitor
Tilt: 30° upward, 90° downward
Swivel: ±90° , View angle: right 178°,left 178°,up 178 °,down 178°
Built-in stereo speaker ,- Brightness and Contrast adjustable .
Monitor on articulating ARM .
TOUCH SCREEN
14” Touch screen
Gesture-control
User configurable UI
Support QWERTY keyboard for text input
Brightness adjustable
TRANSDUCER PORT
5 active ports
5holders (1 dedicated for endocavity transducer)
Electronic Transducer Selection
CONTROL PANEL
Interactive back-lighting
Hard Keys provides tactile feedback
Programmable store keys
Physical trackball
Electronic lift up/down: 20 cm range up
Left / right swivel 90 degree both side .
Retractable keyboard with targeted down lightning .
8 segment TGC sliders
Front and rear handles.
IMAGING STORAGE
1TB SSD.
Storage up to approximately>400,000 lossless single frames
Compression types of static image and clip: lossless, high, mid, low
IMAGE PROCESSING
Tissue Adaptive Imaging(TAI)
Adaptive Doppler imaging - Frequency Compounding Imaging ,- Adaptive Spatial Compounding Imaging ,- Harmonic Imaging ,- Adaptive Speckle Reduction Imaging (eSRI)
Spectrum Enhancement ,- B mode Auto Optimization ,- Color mode Auto Optimization
PW mode Auto Optimization
Digital Multi-Beam Beamforming - Up to 2949120 digital channels
Trapezoid Imaging for linear transducer
B Steer ,- Pan Zoom ,- Spot Zoom
Needle Enhancement Visualization Imaging .
Panorama imaging .
Elastrography .
Auto OB.
Special Compound Imaging (SCI)
Auto IMT
Auto NT.
eVol. Flow
eOB.
eFollicle.
eLV.
POST-PROCESSING
B Mode: gain, TGC, zoom, dynamic range, eSRI, colorize, map
M Mode: gain, TGC, dynamic range, colorize, map
Color Mode: zoom, color map, invert
PW/CW: gain, dynamic range, colorize, map, baseline, angle, invert
Support review images and reportof an exam
Support export images as BMP , AVI or DCM format to removable disk or DVD-R/RW
Support export images as DCM format to DVD-R/RW
Support import/export exams(including patient information, images, measurement results)
Support comments, body mark and measurements in review
CONNECTIVITY
DICOM 3.0
DICOM storage ,
DICOM modality work list.
DICOM MPPS.
DICOM print.
DICOM query / retrieve.
Mobile device transfer optional **
6 USB Ports (4USB 2.0 and 2 USB 3.0)
Video out
VGA,DVI, S-video: PAL/NTSC, -Ethernet.
ECG port (inactive)
Standard DVD-R/RW
Wi-Fi
3D/4D
Acquisition Modes: 4D, Static 3D
Visualization Modes: Volume Rendering, PRs, Multi-Slice
VOI adjustable: curve cut plane
Render Modes: Surface, MIP, X-Ray
3D Clip (2D capture of 3D images))
Cut
Cut tool: trace, box, erase
Function: undo, undo all, redo
Display formats: Single 3D, Dual(A-plane + 3D), Quad(A/B/C Planes + 3D)
Parameters for 3D: Threshold, Smooth, Brightness, Contrast, Tint
eFace: Edan Auto show face
Save and edit volume data set
BIOPSY GUIDE
Optional Available
TRANSDUCERS
1(One No )Convex Transducer -C5-2Q
1(One no) volume convex Transducer – C6-2MQ
1(One No ) Linear Transducer- L12-5Q
1(One No )Phased Array Transducer- P5-1Q
1(One No ) Endo-Vaginal Transducer- E10-3HQ
CERTIFICATION
ISO
European CE
US FDA
