SS Fully Automatic Auger Form Fill Seal Machine
1,389,000 - 1,500,000 / Piece
1 Piece (MOQ)
technical data : eminent ffs-ctm with auger filler fully automatic collar type form fill and seal machine model: eminent-ffs-ctm (pneumatic) product to be packed -powder, atta, basan, maida etc.
machine - ffs collar type pneumatic(mini)
control - plc panel (programmable logic control)
temperature controller- digital temperature control/pid type
unwinding system - simplex
sealing system - heat sealers
roll width - 400 mm (max.) 120 mm (min.)
pouch size - 55mm (width) x 55mm (repeat) [min.}190mm (width) x 300 mm (repeat) [max.]
pouch type - centre seal pouch
filling system - cup filler/multi head weigher /auger filler(optional)
all product contact parts and covering -stainless steel and half ss covering
power consumption- 4 kw.
power supply - 3 phase/440 v + 2% with neutral ac supply at 50 hertz.
compressed air- 6 - 8 cfm @ 4-6 pressure bar
speed - up to 60ppm(depending upon the product and quantity to be packed)output & accuracy depends on following:filling system, characteristics of product to be packed,quantity of product to be packed,consistency in bulk density of the product,consistent level of product in machine hopper,maintaining rh in packing room if the product is hygroscope in nature,
brief details of ffs-ctmm/s eminent engineering services manufacture fully automatic collar type form fill and seal machine which is customized as an intermittent motion machine and designed for the efficient packing of the varieties of products like rice,seeds,tea, namkeen, bhujia, sugar, spices, snacks foods, wafers, detergent, henna powder, salt, wrapper candies,cheese biscuits etc. in center seal pouches.the web path of roll systemized as which keeps on feeding the laminate to the pouch forming tube without much pulling tension to enable the machine to form wrinkle free pouch formation. it is a versatile machine and the pouch width can be changed very easily by replacing theforming tube and collar. changing of the pouch length does not require any change parts. m/s eminent believes in providing the best quality products available in the market to meet the global need.
Number Of Flower : Automatic Form Fill Seal Machines
Application : Food Packaging
Availability : 100-1000kg
Country of Origin : 440V
Condition : New
Power : 1-3kw
Driven Type : Electric
Total Carbohydrate : 1year
Automatic Grade : Automatic
Country of Origin : India
Brand Name : EMINENT PACKS
