Micro Controller Based Nurse Call Monitoring System
Get Price Quote
We are offering micro controller based nurse call monitoring system.
How to monitor and fix-up responsibility.
to ensure the practice is followed, the system must be reliable and must have built in mechanism to point out delay in action.
nurses call monitoring system series 640 informs the nursing staff the sequence of call received thus minimizing any over due call. The call register maintains sequence in which call from different bed are received.
the first call pending is displayed with big 2” 7 segment display. 4 other calls are displayed in the sequence of receipt. If more then 5 calls are pending, the same can be scrolled down. Any call attended is automatically erased and display is replaced with the next call pending.
if any call is pending beyond set time, the number starts blinking. It also activates a buzzer to draw attention of the nursing staff. If call remains pending even beyond 2nd limit, rate of blinking is intensified to bring notice of problem.
• micro-controller based system
• serial display of calls received
-1st call displayed with 2" height led
display, next 4 calls in sequence on side
column, further pending calls- on
scrolling 3 digit 7 segment displays.
• soft tone buzzer
- alerts receipt of new call
• elegant look
• compact and flexible
- table- wall mountable.
• built in non attendance timer
- pending calls flash
- long pending calls flash at higher rates
• modular bed side console
- easy installation in std. Modular cabinet
• status indicators and buttons
- ready, call & wait led indication
on board, with call & reset switch
• elegant patient remote
• low voltage operation
- the system works on 12 v. D.c hence
patient is not put to danger even due to
accidental snatching of wires.
• reset at patient bed
- re-set button installed near the patient.
• compact and flexible
- the system requires very low space and
is flexible to accommodates up to 64 beds.
next generation system from
industry leader
leaders in nurses call monitoring system in india “bps” team is presenting the latest technical innovation in the line.
The system is designed by our in house team to suit indian conditions.
system over view
series 640 consists of mainly the following sub-systems:
a) call station board
b) patient remote hand set
c) door indicator
d) toilet pull cord
e) master controller hub
f) nurses monitor console
call station board
each bed is provided with call station board. This is housed in standard console. It has push switches to call and re-set the call.
led indications for ready(green), call(red), and wait(yellow) are provided. Ready led indicates that the system is ok and call can be made. If there is any problem with wiring, it will not glow. This is built in system to give instant check of any system or wiring fault.
led marked call lights up when the call is made. Once the call is made and it is registered with the controller hub, led marked wait glows indicating call has reached nurse station.
patient remote hand set
from call station, remote patient hand set is provided so that the patient can make call form his bed.
Remote hand set has push to make call. Led indication for ready, call and wait are provided.
door indicator
door indicator is installed out side the room to indicate call pending in the room. This facilitates nursing staff to attend on way to nurse station. One door indicator can announce pending call for
up to 8 beds in the same room. Door indicators are available with many features like color leds, hold switch etc.
toilet pull cord:
toilet pull cord with indicator & rope. Standard length of rope is 1.5m. This pull cord is installed in side the toilet. Patient can use the pull cord in toilet.
master controller hub:
controller hub is central unit installed near nurse monitor console. It is consisting of one
micro-processor central controller card, one connector card for up to 16 beds smps.
Wires from all beds are terminated on connector pcb. It receives information from
each bed and signals the console to display the information.
nurses monitor console
the call monitor console will be installed at the nurse center. Call received from any bed will be displayed by the respective bed number by 3 digit 7 segment led display. It can be mounted on wall or table stand. The first call pending is displayed with big 2” 7 segment display. Other 4 calls are displayed in the sequence of receipt. If more then 5 calls are pending, the same can be scrolled down.
Any call attended is automatically erased and display is replaced with the next call pending.
connections:
two pair telephone cable will be required to connect each bed to display board. Telephone type socket is punched to wires from each bed. Mains supply of 230 v ac is required at controller hub.
low voltage operation:
the incoming mains is converted to 12 v. D.c. In the power supply section and patient is not put to danger even due to accidental snatching of wires.
re-set at patients bed:
to re-set, the nurse or attendant has to press a button installed near the patient. This ensures attendance.
compact and flexible:
the system requires very low space and is flexible to add on as the number of beds increases. Marking on he indication board can be custom designed for easy location and is editable.
our expertise
nurses call monitoring systems and queue management systems by team “bps” is installed in all the leading hospitals in eastern india.
With over 15 years of feed back from actual working condition in hospitals, continuous improvement in design, innovation of technology we are presenting series 640-the most advanced nurses call monitoring system.
The system is designed with utmost reliability, dependability, safety, and flexibility in mind.
ordering information
item description model no. quantity reburied
call station board with membrane push switches for call and re-set buttons
& leds for ready, call and wait, connector for console connection
and connector for patient remote hand set bncm-pb640a each bed = 1 set
patient
remote handset with flexible wire of 2 meters, telephone type jack connector,
switch for call and indication for ready, call & wait bncm-pb640r each bed = 1 set
door indicator with 8 nos red leds, red acrylic cover for connecting up to 8 beds
in one room bncm-du-1 optional
with 3 colour leds, flash study off functions, acknowledge push,
acrylic cover suitable for connecting up to 4 beds in one room bncm-du-2 for each room
toilet pull
cord toilet pull cord with indicator
rope length standard 1.5 m bncm-tpc1 for each toilet
master controller
hub type-1 with one micro-processor central controller card, one connector card
for up to 16 beds, power supplies (smps) housed in hinged cabinet bncm-mch640a up to 16 beds
master controller
hub type-2 with one micro-processor central controller card, two connector card
for up to 32 beds power supplies (smps) housed in hinged cabinet bncm-mch640b up to 32 beds
master controller
hub type-3 with one micro-processor central controller card, three connector card
for up to 48 beds power supplies (smps) housed in hinged cabinet bncm-mch640c up to 48 beds
master controller
hub type-4 with one micro-processor central controller card, four connector card
for up to 64 beds power supplies (smps) housed in hinged cabinet bncm-mch640d up to 64 beds
nurse monitor
console with one 2" height & 4 nos 34" height led display
suitable for wall mounting and with table stand bncm-nch640a up to 64 beds
data logger card computer interference card with software
fitted in enclosure bncm-dlc-2 optional
up to 64 beds
wires from bed
to call station 2 pair telephone wire as per distance from beds to
call station
