Multi Page Quad Switcher
Features : (Maximum Up to 16 Cameras)
• Hitech Desktop or Split Switcher integrated with Quad
• Works with both B/W as well as Colour Quad
• Cameras can be selected Individually or in Quad form (1to4, 5to8, 9to12 and 13to16)
• Individual Dwell Time Setting for each Camera and Quad Screen from 01 to 99
Seconds in AUTO Mod
• Self- Diagnostic (LED Indication in case of Communication Failure)
• Available only in Video.
Specifications :
Model : VS-n IDT
Available Camera Inputs : 4,8,12,16
Display(Slave) : LED – Power (Red) and Communication (Green)
Camera Input : RCA
Quad Interface : 4 RCA for Quad Input and 1 RCA for Quad Output
Video Input : 1V p-p Composite, 75 ohms
Video Output : 1 V p-p Composite, 75 Ohms
Power Supply : 220V AC, 500mA
Operating Temperature : 0 ° C to 50 ° C
