JB Hydraaulics Pudur, madurai, Tamil Nadu

Specification Unit JB 150 VSE 1. Clamping Force Ton 150 2. Top Platen Size mm 420x420 3. Bottom Platen Size mm 400x450 4. Cylinder Bore Dia mm 300 5. Stroke / Day Light Gap mm 250 6. No. of Day Lights No. Single 7. Pump Pressure kg/cm² 200 8. Power Pack Tank ltrs 400 9. Motor HP 10 10. Presses No. 2 11. Approach Speed mm/sec 30 12. Closing Speed mm/sec 6     VACUUM SYSTEM VACUUM PRESS - REDUCE REJECTIONS & INCREASE PRODUCTIVITY.   Avoids Atmospheric air to enter the Mould area. It eliminates erosion from gases fumes & improves life of the Mould. Reduces Heat Loss due to which Transfer of heat to mould & product will Increase. Helps to increases Temperature of the platens. Reduces rejections & Increase productivity.

Ejection System Designed to handle the bigger size & Heavy Moulds without fatigue / Ease. Available for 2 piece 3 piece & 3 piece Mould with product ejection. Easy to take the finished product, cleaning the Mould & reloading of material. Operated by hydraulic Cylinders & Controlled by electrical Sensors. Firm & Solid Design for prolnged life. Safety features Included.

Compression Press Available in various Tonnages ranging from 10 Tons to 500 Tons. HEATING PLATENS to suit existing & New Moulds MINIMUM PLATEN SIZE for Minimum Cavities & MAXIMUM PLATEN SIZE for Maximum Cavities. Operator friendly as the working height of our press is around 1 meter. This allows the operator to reach the mould & Cavities very Conveniently. Press Designed for Minimum Deflection maintaining High parallelism of platens. Hydraulic Operated with best Sealing technologies. Branded Hydraulic & Electrical Accessories for prolonged life of press. Optional  Wear Plate To maintain High parallelism. To protect the platen from damages due to to mishandling of Moulds.   Mould Slide In - Out Arrangement Slides the mould out to take the Finished product thus reducing the risk of the operator getting burn due to platen heat. Increases productvity as the time of taking the finished product cleaning & reloading of material is easy. Risk of Misallignment of Moulds is Minimum. Reduces damages & Increases life of the Mould. Both Mechanical & Hydraulic arrangements are available. Safety features Included.   Ejection System Designed to handle the bigger size & Heavy Moulds without fatigue / Ease. Available for 2 piece 3 piece & 3 piece Mould with product ejection. Easy to take the finished product, cleaning the Mould & reloading of material. Operated by hydraulic Cylinders & Controlled by electrical Sensors. Firm & Solid Design for prolnged life. Safety features Included.   VACUUM SYSTEM VACUUM PRESS - REDUCE REJECTIONS & INCREASE PRODUCTIVITY. Avoids Atmospheric air to enter the Mould area. It eliminates erosion from gases fumes & improves life of the Mould. Reduces Heat Loss due to which Transfer of heat to mould & product will Increase. Helps to increases Temperature of the platens. Reduces rejections & Increase productivity.

Compression Press Available in various Tonnages ranging from 10 Tons to 500 Tons. HEATING PLATENS to suit existing & New Moulds MINIMUM PLATEN SIZE for Minimum Cavities & MAXIMUM PLATEN SIZE for Maximum Cavities. Operator friendly as the working height of our press is around 1 meter. This allows the operator to reach the mould & Cavities very Conveniently. Press Designed for Minimum Deflection maintaining High parallelism of platens. Hydraulic Operated with best Sealing technologies. Branded Hydraulic & Electrical Accessories for prolonged life of press. Optional  Wear Plate To maintain High parallelism. To protect the platen from damages due to to mishandling of Moulds.   Mould Slide In - Out Arrangement Slides the mould out to take the Finished product thus reducing the risk of the operator getting burn due to platen heat. Increases productvity as the time of taking the finished product cleaning & reloading of material is easy. Risk of Misallignment of Moulds is Minimum. Reduces damages & Increases life of the Mould. Both Mechanical & Hydraulic arrangements are available. Safety features Included.   Ejection System Designed to handle the bigger size & Heavy Moulds without fatigue / Ease. Available for 2 piece 3 piece & 3 piece Mould with product ejection. Easy to take the finished product, cleaning the Mould & reloading of material. Operated by hydraulic Cylinders & Controlled by electrical Sensors. Firm & Solid Design for prolnged life. Safety features Included.   VACUUM SYSTEM VACUUM PRESS - REDUCE REJECTIONS & INCREASE PRODUCTIVITY. Avoids Atmospheric air to enter the Mould area. It eliminates erosion from gases fumes & improves life of the Mould. Reduces Heat Loss due to which Transfer of heat to mould & product will Increase. Helps to increases Temperature of the platens. Reduces rejections & Increase productivity.
