Features   Design as per GMP SS316L & Teflon version available Double bearing design High impact cleaning Low water consumption/li> Self rotating nozzles Self retracting Pop-up design for Isolators High impact jet nozzles.

Compact straight jet with a defined jet length owing to optimum flow geometry. Flow conditions are not affected by turbulence. A concentrated jet with high impact force is achieved. This is used for powerful punctiform impact, wherever concentrated jet power is vital. Characteristic : A high efficiency and economical performance is obtained.   Design : One Piece Construction.   Application : For High pressure cleaning systems, Jet Cutting and separating.   Features : Optimized flow maximum jet power concentrated energy.

Features   Application : Continuous Casting Cooling. Spray Characteristics : 1] Produces a full cone pattern2] Sprayed volume is evenly distributed across spray pattern3] Available with a range of spray angle Materials and Construction :1] Standard materials are Brass and Stainless Steel2] Male and female thread available3] 3/8" or 1/4" BSP / NPT threaded connections available4] Specially designed internal core ensures a good resitance to clogging

Oil burner nozzles are available in semi hollow cone spray pattern. Micro-finish of tip & disc seats permitting flow only through the slots of the disc, plus extremely close manufacturing tolerances, ensure accurate capacity control. These nozzles are fitted with filter in order to provide highly efficient in depth filtration with one piece construction extra fine filter microns are supplied as standard on all small capacity nozzles.   Application : LDO firing in kilns of cement, sponge,Iron plants & Dust suppression.   Range: Spray Angle : 45º,60º,70º,80º & 90º.Flow rate (GPH) at 100 PSI Pressure : 2.50, 3.00, 3.50, 4.00, 4.50, 5.00, 5.50, 6.00, 6.50, 7.00...... GPH.Connection: UNEF 9/16”M.O.C. : SS 303

Full Cone Spray Nozzle form complete spray coverage in a round area. It provides an uniform spray distribution of medium to large size drops resulting from their vane design which features large flow passage and control characteristics. Characteristic : Internal vane design features large flow passage and fine control. Design : Removable vane, Axial flow. Type : Round pattern, Threaded connection

Design : One piece construction, Non clogging type. Application : Rinsing, Lubricating, Industrial washing machines, Cake washing in Centrifuge, CIP, Tray washing. Flat Spray Nozzle are designed for high pressure / high impact washing application. These nozzles are specially designed and machined with precision which allows even spray coverage and distribution. This results in effective and uniform cleaning action over the surface being processed. Flat spray nozzles are available in all steel grades, Plastics & other alloys. Spray angle range available from 15º to 120º

Fire Fighting spray nozzles are used in deluge water spray system for special hazard fire protection application. We offered spray nozzles are made available in several combinations of orifice sizes and spray angles. These spray nozzles have an external deflector, which discharges water in a directional cone shaped pattern of small droplet size.   Features   Maximum Working Pressure: 12 Bar Easy to rotate Natural Brass Finish

Air Atomizing Spray Nozzle mixes liquid & air to give fine mist like formation. In common situation we can get super fine liquid spraying drops. Adjustable atomized nozzles can adjust liquid capacity and it can meet the requirement of spraying without changing air pressure and hydraulic pressure therefore it has good adaptability. Each spray device is composed of air cap and liquid cap which can offer two spray modes flat fan and round with wide liquid capacity coverage. There are various available sizes of inlet joint for these type of Spray Nozzles. It is flexible with changeable parts. Atomizing Nozzle has good moisture effect. It is the ideal choice for the location where requires moisture control.
