Sci-tech Pressure Measurement Bench Model FM 43 is a self-sufficient unit to study the fundamental concept of Pressure Measurement and Various Pressure measurement Devices. The set-up consists of an Air blower supplying pressurized air. Arrangements are made to connect different pressure measuring devices to the Air supply & understand use of them. The pressure measuring devices include set of Manometers, set of Bourdon type gauges, Barometer etc. SYSTEM COMPONENTS AVAILABLE INDIVIDUAL or SET v Manometers- Ø U Tube Manometer: Acrylic; 0 – 1000mm H2O Ø Single Limb Manometer: SS; 0 – 2.0 kPa Ø Inverted tube Manometer Ø Incline tube Manometer: Acrylic; Range 0 – 3 H2O Ø 6 Tubes Multi-Tube Manometer Ø 11 Tubes Multi-Tube Manometer Ø 36 Tubes Multi-Tube Manometer (Optional) v Vacuum Pump: @15LPM Capacity; 22” Hg max vacuum; 20psi max pressure (US$ 350) v Pressure Gauge: 0 – 35psi; SS; Oil filled (US$ 60) v Vacuum Gauge: 0 - 760 mm of Hg;; SS; Oil filled (US$ 75) v Differential Pressure Gauge: Al or SS cover; 30 psi max (US$ 95) v Vacuum Tank: SS; 1.1L capacity v Pressure Calibrator: Operating Range 2bar/28psi; Over Range 4 bar / 58psi v Centrifugal Blower OPTIONAL ACCESSORIES v Multimedia computer based training package on pump construction & characteristics. v Cut sections of valves & pumps LIST OF EXPERIMENTS v Study of Pressure measuring System. v Study of Barometer. v Pressure measurement using different Manometers. v Pressure measurement using Bourdon type Pressure Gauges. OPERATION & MAINTENANCE MANUAL Self-explanatory operating & maintenance manual will be provided. This will include Theory, operating procedure, standard results, and maintenance procedures. v Transparencies & Slides
