Primary Injection Test Set Dealers in Mumbai

(10 products available)

All IndiaMumbaiChennai Nashik Delhi Thane Gurugram Bangalore Kolkata Pune Surat

Current Injection Test Unit

Get Price Quote

MaterialMetal, Electronic Components
UsageTesting And Calibration Of Protective Devices
Current Range100A To 15000A
Voltage Range2V To 10V

Protective devices such as over current relay, short circuit relay, circuit breakers and CTs etc must be checked and calibrated regularly to ensure that they are always ready to operate correctly. Current injection testing sets will help detecting faulty or incorrectly adjusted protection circuit / device and thereby avoid damage to the system. With the help of current injection test sets the correct functioning of protective device / circuit is ensured. The units are available in single phase version for small capacity and single or two phase version for higher capacities. Features Primary Current Injection test set basically provided high currents ( From 100 to 15000Amps) at lower voltages (From 2V to 10V) Continuously variable outputs (0 to rated current) Dimmerstat (Continuously Variable Voltage Auto Transformer) Double wound loading transformer Built – in Analogue Ammeter with C.T. Time Interval Meter from .0001 sec to 9999 sec (auto ranging facility) – Optional

...more
Automatic Electric Limited

Wadala, Mumbai

8 yrs
Primary Injection Test Set

Get Price Quote

Input power Supply220 Volts ± 10, 50HZ AC single phase
Output Test CurrentRefer Table no.1
Output Test Current RangeRefer Table no.1
Duty Cycle10 minutes ON -20minutes OFF
Mode of OperationManual or Motorized
Protections and SafetyOverload Protection by MCB. HRC fuse protection for control circuit
IndicationsBright LED Indicators are provided for Input and Output Indication
CoolingAir/Oil Cooling
ControlOne Knob control to vary Output current

The Giri Trading make Primary Current Injection Kit (PE-PIK) is well suited to check the operation of all the components in a circuit breaker including Current Transformer, current sensors, relays and tripping unit performance of circuit breakers. Application Giri Trading make Primary Current Injection Kits are used to test Circuit Breakers, Bus Bars, CTs, Relays, MCBs, MCCBs etc. These are also used for high current injection during commissioning of protection systems and after major repairs and cornponent replacernent in power substations. Features Single compact unit equipment for easy operation. The kit is designed to offer continuously variable output current. Built in Digital timer for measuring tripping time. Digital meter of Accuracy class 0.5% or better and with LED display for Displaying input voltage 8, output currents. The kit is having adequate MCB protection to protect from overloads. Accessories Out put cable : One pair of copper flexible cable each of 3 Mts long duly fixed with Heavy Duty Crocodile Clip and Copper lugs or as per customer requirement. Instruction Manual. Calibration Report. Warranty Card Display /Metering A Digital Ammeter of 96*48 mm size having accuracy class 0.5 or better to measure output current. 1 No. Digital Voltmeter 96*48 mm size with Accuracy class 0.5 or better to measure input voltage. Inbuilt digital time interval meter with range from 0.0001sec. to 9999 sec. to measure tripping time.

...more
Giri Trading

Sakinaka, Mumbai

GST 6 yrs
Primary Current Test Set

Get Price Quote

Automation GradeAutomatic
FeatureEasy To Install, Electrical Porcelain, Proper Working, Superior Finish
Country of OriginIndia

We offer new generation intelligent high-current generator. Power, electrical industry needs a large current output in testing and debugging necessary equipment. Intelligent High current generator is widely used in power companies, power plants, power distribution stations, electrical factories and research institutes other departments. Features: 1. Current, Voltage, time, status information are displayed on 4.7â�� large-screen LCD, and is very easy and clear to read. 2. Interface is in English, operation is very simple, can be used in a variety of applications; 3. All operations of the intelligent current generator are through front panel mounted keypad. All functions can be set via key pad and hence it improves the product safety and reliability. 4. Calibration is fully digital, no potentiometers are involved, it is extremely site friendly with password protection; 5. All status messages/ warnings are presented on the display and hence operation is possible without skilled manpower. 6. When the test is going on High voltage sign is continuously flashing on the display and adds to the safety of the operator. 7. Pause function provides flexibility in operation. Rise and fall of current can be paused any time this it gives the operator to chance to observe the response of the test object to the injected current.

...more
www

Myriad Industrial Solutions LLP

Dahisar, Mumbai

GST 12 yrs 4.7 (30)
Primary Injection Test Set

Get Price Quote

Capacity1kVA to 10kVA
Current output200A to 4000A

Testing especially if the protective fear is connected to the power line via a current transformer it is advisable to carry out primary injection testing These sets have been designed to enable the users of heavy electrical equipment to carry out such tests as have been described above with a maximum efficiency at minimum cost, providing a convenient of delivering, controlling and measuring a heavy current in a comparatively low voltage low impedance circuit. Ideal for testing circuit breakers, ammeters with or without current transformers and much other application where a heavy current supply of short duration is required

...more
NEON CONTROLS

Ghatkopar West, Mumbai

GST 12 yrs
Primary Injection Kit

Get Price Quote

FeatureDigital meters for display of voltage & current Digital time interval meter range from 0.0001 sec to 9999 sec

The MOTWANE make primary injection kit (MOT-PIK) has different models with range of output currents from 100A to 3000A.These are well protected with the provision of MCB against OVERLOAD than the rated current. HRC fuse protection is provided for control circuits. Bright LED indicators are provided for indicating input output status. The PIK comes with adequate cooling systems like airoil cooling depending upon the ratings. It is having one knob control to vary output current. The PIK can be utilized for high current injections during commissioning of protection systems, testing after major repairs equipment replacements in power sub stations.

...more
Renuka Enterprises

Dombivali, Mumbai

9 yrs
Primary Injection Test Set

Get Price Quote

Udey PCT series comprises of two units: 1) a control unit and 2) a loading unit. Thus making the tester compact and portable. Four models are available with outputs from 250 A to 3000 A. The control unit offers a current output of 0-10 Volt at 50 Amp or 0-5 Volt at 100 Amp. Additionally, a separate voltage output of 0-250 V AC is available for testing voltage operated relays coils or checking the magnetization characteristics of current transformers.
...more

Udeyraj Electricals Pvt Ltd

Marol, Mumbai

16 yrs
Current Injection Test Unit

Get Price Quote

Current Injection Test Unit, DC Energy Mete

Automatic Electric Ltd.

Andheri East, Mumbai

9 yrs
Primary Current Injection Test Kit 3 - 2000

Get Price Quote

Primary Current Injection Test Kit 3 - 2000, Circuit Breaker Time

S K Electronics Power House

Dombivali, Mumbai

9 yrs
Primary Injection Test Set

Get Price Quote

Lomas Primary Injection Test Set is a versatile compact apparatus designed to give standard output current upto 1000 Amps from an input of 230 Volts AC. Test Sets to suit any other input voltage or with higher output can be catered for by order. This wide range of variation in output is obtained with smooth regulation and least wave form distortion. By using the Primary Injection Test Set, functional checks involving high currents can be carried out at low cost and with inherent safety requiring minimum precautions. Application:-It has wide field of applications in testing supply net work, high current circuits and phantom loading.
...more

Lomas Electrical Engineering Pvt. Ltd.

Andheri, Mumbai

8 yrs
Primary Injection Test Set

Get Price Quote

Primary Injection Test Set, Tan Delta Test Se

Vivid Metrawatt

Vasai, Mumbai

9 yrs
