360° mechanical, continuous rotationAll Symphonie Data Loggers
Analog DC voltage from conductive plastic potentiometer, 10K ohmsOutput signal is a ratiometric voltage
Potentiometer linearity within 1%8° Maximum, 4° Typical
RNRG 200P Wind Vane
The 200P Wind Vane is one of the most widely used wind direction sensors in wind, solar, and meteorological applications worldwide.
Constructed of thermoplastic and stainless steel components, the 200P resists corrosion and features a high strength-to-weight ratio. The 200P is directly connected to a precision conductive plastic potentiometer located in the main body. When a constant DC excitation voltage is applied to the potentiometer, it produces an analog voltage output directly proportional to the wind direction.
The 200P includes a PVC terminal boot for additional protection from the elements.
