Detailed Specifications:
Electrochemical Methods: CV, LSV, ChronoAmp, OCP, DPV, SWV
Channels Per Unit: 1
Applied potential range: ±2.4 V
Applied Potential Accuracy: 0.1% of the setpoint, 1mV Max
Applied Potential Resolution: 76 µV
Measured Potential Accuracy: 0.1% of the setpoint, 1mV Max
Measured Potential Resolution: 156 µV
Compliance Voltage: ±8 V
Maximum Current: 30mA / 100 mA
Current ranges: 7 Ranges
Measured Current Accuracy: 0.1% of the range, 1nA max
Measured Current Resolution: 0.00015% of range, 1.5 pA
Input Impedance: >10 TΩ
Input Bias Current: 1pA Max
Computer Interface: USB
Channel Cable Length: 0.8 meter
power supply: 12V DC
Power Supply Requirements: 100V - 240V AC
Weight: 285 gram
Physical Dimensions: 181mm * 91.5mm * 42mm
Operating temperature range: 0 to 50°C
Communication: USB, Bluetooth
Bandwidth: upto 4 MHz
Max. acquisition rate: 1 KHz
ADC/DAC Resolution: 16 bit
Slew Rate (No Load): 3.5 V/µS
Maximum Sampling Speed: 50,000 samples/sec
