EPS Cup Making Machine, a high-end cup making machine aims to take productivity of a unit to a next level. Developed with revolutionary technology, EPS Cup Making Machine uses efficient working principle for rendering best services. Our EPS Cup Making Machine is greatly demanded for its remarkable workability and longer service life. Application : EPS Cup Making Machine facilitate EPS raw material to expand to the required density Features :
Strong M.S. structure
S.S. shell
5-Hp. Motor with reduction Gearbox
2- Hp. Motor with High flow Blower
EPS raw material Feeding screw device with 1-Hp. Motor & Hopper
Parameter control : All manual operation Material Expander
Material Expanded Jar Size : Φ 800 *H1200 (mm)
Steam Pressure : 0.3-0.6MPA
Air Pressure : 0.3-0.6MPA
Foaming Ratio : 20~50
Foaming Error (Grain) : �10%
Output : 50-160KGS/H
Power Consumption : 3KW/H
External Power Supply : 3-phase 380V 50Hz
Machine Size : 1400mm*800mm*2500mm
Machine Weight Approx. : 1.2T
Dryer
Output of Air-drying :150-200KGS/H
Power : 6.6KW
Machine Size : 4000mm*800mm*1000mm
Central Feeding System
Blower Power : 3 sets, 2.2KW
Bigger Hopper : 2 pcs,3000mm*3000mm*3000mm
Small Hopper : 2 pcs,800mm*800mm*500mm
