Timer32; 0.1 sec, 1 sec, 1 min settable (retentive).
Counter16, UP, DN and UP-DN.
High-speed counter2(16 bit, 5 KHz).
Self DiagnosticWD timer, memory check.
Word memory256 words.
Flags512 (retentive).
Feature Highlights
A ULTRA COMPACT model micro.
Sub-Models with analog I/O.
Flexible & expandable via networking.
Fully ON-LINE Programmable by HHP.
24 VDC operated.
Adopts MODBUS protocol for networking.
Front end I/O termination with plug in type connector.
Modular construction permits easy replacement of input, output and CPU Cards.
Optional RTC.
Analog I/O handling capability.
Non-volatile EEPROM storage.
High-speed inputs.
Retentivity for Timers / Counters.
35mm DIN rail mounting or wall mounting.
Feature Highlights
A ULTRA COMPACT model micro.
Sub-Models with analog I/O.
Flexible & expandable via networking.
Fully ON-LINE Programmable by HHP.
24 VDC operated.
Adopts MODBUS protocol for networking.
Front end I/O termination with plug in type connector.
Modular construction permits easy replacement of input, output and CPU Cards.
Optional RTC.
Analog I/O handling capability.
Non-volatile EEPROM storage.
High-speed inputs.
Retentivity for Timers / Counters.
35mm DIN rail mounting or wall mounting.
Introducing the Data loggers that controls and also records the data. Our SERIES 951 provides you efficient data retrieval with ideal control and data acquisition solution. Feature Highlights
1/4 DIN size package.
Microprocessor based accuracy.
Alarm capabilities with relay outputs.
8 ch, 16 ch, or 24 channel models.
AUTO / MANUAL mode facilities.
Addressable serial interface.
Retain set up during power loss.
Data storage for analysis using standard 80 columns printer.
Lower cost of ownership. Universal input, can be selected on site.
Memory available 8K, 16K & 32K.
Alarm relay board for 8 ch,16 ch,24 ch available.
Multidrop RS 485 connectivity.
Size: 96 x 96 x 120 mm.
Introducing the Data loggers that controls and also records the data. Our SERIES 951 provides you efficient data retrieval with ideal control and data acquisition solution. Feature Highlights
1/4 DIN size package.
Microprocessor based accuracy.
Alarm capabilities with relay outputs.
8 ch, 16 ch, or 24 channel models.
AUTO / MANUAL mode facilities.
Addressable serial interface.
Retain set up during power loss.
Data storage for analysis using standard 80 columns printer.
Lower cost of ownership. Universal input, can be selected on site.
Memory available 8K, 16K & 32K.
Alarm relay board for 8 ch,16 ch,24 ch available.
Multidrop RS 485 connectivity.
Size: 96 x 96 x 120 mm.
Operating ModesAuto/Manual, settable through front keypad.
Accuracy0.01% full scale.
Repeatability+/- 1 count.
Set point resolution0.1/1 count.
Dimensions96 x 96 x 120 mm(Model 751-H)
Input2 wire or 3 wire RTD or Thermocouple or process inputs like 4-20mA, 0-5VDC.
No. of Inputssingle, double on request for application like ratio control.
The SERIES 751 digital single loop controller is a welcome addition to MICROCUBS process control series.
This series features a comparable accuracy and reliability to conventional digital controllers with full flexibility in both setup and operation.
Algorithms for advances PID, PI , P or on/off control strategies makes the SERIES 751 controller a valuable automation tool.
Feature Highlights
1/4 and 1/8 DIN size package.
Direct sensor connections for Thermocouples, RTDs, as well as 4-20 mA and 0-5 VDC.
Choice of control algorithm:can be configured as standard PID, Split (Heat/cool), Time proportional ON/OFF or DIAT type control output; thereby suited to wide range of applications.Status indication of relays and the process at a glance on the LED's.1/4 and 1/8 DIN size package.
Direct sensor connections for Thermocouples, RTDs, as well as 4-20 mA and 0-5 VDC.
Choice of control algorithm:can be configured as standard PID, Split (Heat/cool), Time proportional ON/OFF or DIAT type control output; thereby suited to wide range of applications.
Status indication of relays and the process at a glance on the LED's.
Addressable Serial interface either RS 232 or RS 485 for communication with
Retain set-up during power loss without batteries.
The SERIES 751 digital single loop controller is a welcome addition to MICROCUBS process control series.
This series features a comparable accuracy and reliability to conventional digital controllers with full flexibility in both setup and operation.
Algorithms for advances PID, PI , P or on/off control strategies makes the SERIES 751 controller a valuable automation tool.
Feature Highlights
1/4 and 1/8 DIN size package.
Direct sensor connections for Thermocouples, RTDs, as well as 4-20 mA and 0-5 VDC.
Choice of control algorithm:can be configured as standard PID, Split (Heat/cool), Time proportional ON/OFF or DIAT type control output; thereby suited to wide range of applications.Status indication of relays and the process at a glance on the LED's.1/4 and 1/8 DIN size package.
Direct sensor connections for Thermocouples, RTDs, as well as 4-20 mA and 0-5 VDC.
Choice of control algorithm:can be configured as standard PID, Split (Heat/cool), Time proportional ON/OFF or DIAT type control output; thereby suited to wide range of applications.
Status indication of relays and the process at a glance on the LED's.
Addressable Serial interface either RS 232 or RS 485 for communication with
Retain set-up during power loss without batteries.
Feature highlights
1/4 DIN size package.
Universal Input for Model 5351. For model 751-P,input should be specified before ordering.
Single or dual control loops.
Optional RS232 or RS485 communication ports.
User programmable Set point profiles: up to 10 programs of 16 segments each & 1event relay.
One optional analog output.
Alarm / control capabilities with more I/Os.
Addressable serial interface to communicate. with higher-ranking system.
Optional printer interface for data storage.
Choice of control algorithms.
Feature highlights
1/4 DIN size package.
Universal Input for Model 5351. For model 751-P,input should be specified before ordering.
Single or dual control loops.
Optional RS232 or RS485 communication ports.
User programmable Set point profiles: up to 10 programs of 16 segments each & 1event relay.
One optional analog output.
Alarm / control capabilities with more I/Os.
Addressable serial interface to communicate. with higher-ranking system.
Optional printer interface for data storage.
Choice of control algorithms.
To change active parameters.
To set Operating parameters.
Display Process, Alarms, & faulty Conditions.
Connectivity through RS 485 / RS 232.
Can be connected to any Microcub range of product.
Display : 2 line 24 character LCD display with Back light.
Function key available to asign with operating parameters.
L.96, W.144, D.120 mm.
To change active parameters.
To set Operating parameters.
Display Process, Alarms, & faulty Conditions.
Connectivity through RS 485 / RS 232.
Can be connected to any Microcub range of product.
Display : 2 line 24 character LCD display with Back light.
Function key available to asign with operating parameters.
L.96, W.144, D.120 mm.
Input:2 wire or 3 wire RTD or Thermocouple or process inputs like 4-20mA, 0-5VDC.
Accuracy:0.01% full scale.
Feature Highlights
Compact 1/4 and 1/8 DIN size package.
Microprocessor based.
Fully linearised.
Touch keypad setting.
Hysterisis settable and constant throughout the range.
Available Models: 870-S & 870-H for Single set point and 870-D & 870-HD for
870-HD for Two set points Controller.
Feature Highlights
Compact 1/4 and 1/8 DIN size package.
Microprocessor based.
Fully linearised.
Touch keypad setting.
Hysterisis settable and constant throughout the range.
Available Models: 870-S & 870-H for Single set point and 870-D & 870-HD for
870-HD for Two set points Controller.
Microcub introduces our SERIES 3240 DC drives with simplicity and reliability to meet all your application needs for DC motor speed control. The series is specifically designed to provide higher accuracy and absolute repeatability at an economic price. The series covers a range of applications from 0.5 HP to 100 HP . Feature Highlights:
3 sub-models as per rating.
Fault status indication by LEDs.
Built in soft-start & soft-end.
Can be controlled by external process variables like 4-20 mA or 0-10 VDC.
Current limiting, limit adjustable by user.
Field failure protection.
Maximum & minimum speed settable.
IR compensation.
Compact, Lightweight.
Optically isolated (Optional ).
Microcub introduces our SERIES 3240 DC drives with simplicity and reliability to meet all your application needs for DC motor speed control. The series is specifically designed to provide higher accuracy and absolute repeatability at an economic price. The series covers a range of applications from 0.5 HP to 100 HP . Feature Highlights:
3 sub-models as per rating.
Fault status indication by LEDs.
Built in soft-start & soft-end.
Can be controlled by external process variables like 4-20 mA or 0-10 VDC.
Current limiting, limit adjustable by user.
Field failure protection.
Maximum & minimum speed settable.
IR compensation.
Compact, Lightweight.
Optically isolated (Optional ).
Secondary Business TypeManufacturer / Exporters / Wholesale Suppliers
Opening Hours
SUN : Closed
MON : 9:30 AM - 6:30 PM
TUE : 9:30 AM - 6:30 PM
WED : 9:30 AM - 6:30 PM
THU : 9:30 AM - 6:30 PM
FRI : 9:30 AM - 6:30 PM
SAT : 9:30 AM - 6:30 PM
Microcubs Systems Pvt Ltd is the provider of the Process control Instrument product line. We started to manufacture these automation line products from 1992. Since then, we are providing the simple solutions with powerful technology. Microcubs has been providing quality electronic design with the product reliability at its most. Our tremendous growth over the years is a result of providing our customers with high quality products and services. We understand our customer's need to be first to market while maintaining outstanding product quality. Our products are manufactured in our modern Ten Thausand square foot facility located in Pune , India. State-of-the-art manufacturing equipment allows us to provide quick turnaround on orders while maintaining our competitive edge. Microcubs is committed to keep the automation line, a force in the market place by providing top quality products. We are improving and adding to the product line and would welcome any feedback you might have regarding the our product. Our 15 years of experience in the design and manufacture of instrumentation & automation line products has earned us a reputation for providing products with reliable performance, accuracy and convenience. It is no wonder that customers from various industries turn to Microcubs for quality products and services. We invite you to explore our product line and let us help you find the right solution for your automation needs.
