PS-01 Single Channel Transmitter Power Supply
Product Description
The Electronet PS-01 is a compact single-channel transmitter power supply designed to deliver stable 24V DC output for field instruments. It is ideal for locations where a reliable DC supply is not readily available. With a maximum current rating of 100 mA, the PS-01 efficiently powers transmitters and process instruments used in industrial automation. Its DIN rail mounting, compact size, and durable ABS enclosure make it suitable for control panels, saving space while maintaining a clean installation layout.
Key Features
Single-channel power supply
24V DC output, 100 mA max
Compact design for space-saving installation
Suitable for transmitters & field instruments
DIN rail mounting for easy setup
Stable, regulated power output
Technical Specifications
Performance Characteristics
No. of Inputs: 01 No. of Outputs: 01
Input Specifications
Input Voltage: 230 VAC, 50 Hz ±10%
Output Specifications
Output Voltage: 24V DC
Current Rating: 100 mA max
Line Regulation: < +30 mV DC
Load Regulation: < 1.5% per amp
Output Ripple: < 20 mV RMS
Protection & Electrical Parameters
Isolation: 1.4 KV between input & output
Short Circuit Protection: Provided
Temperature Coefficient: +0.01% per °C
Mechanical & Environmental Details
Enclosure
ABS Plastic (durable & lightweight)
Dimensions
60 mm (H) × 70 mm (W) × 110 mm (D)
Mounting
DIN Rail Type
Weight
Approx. 0.5 kg
Operating Conditions
Temperature: 0°C to 55°C
Humidity: 5% to 95% non-condensing
