Three Way Valve Dealers in Pune (13 products available)

• Size: 25mm to 300mm
• Type: 3 Way Ball Valve
• Material: Carbon Steel, Stainless Steel
• Certification: ISI Certified, ISO 9001:2008 Certified
• Application: Air Use, Gas, Liquid
• Weight: 10-15kg, 15-20kg, 20-25kg, 25-30kg, 5-10kg
• Color: IPL Std
• Condition: New
• Pressure: Low, Medium
• Feature: Durable
• End Connection: Flanged
• Number Of Way: 3
• Pressure Rating: # 150 / # 300
• Sizes: 1' to 12"

• Feature: Investment cast body construction/Bar stock Construction, Blow out proof stem & Anti static device etc.

Series 1530L&T- is a versatile large size multi-port ball valve. It can be configured as a three-way valve with "L" or "T" ports. It consists of a heavy-duty centre section with bolted-on flanged ends for Class 150 flanges, Class 300 Flanges. All body gaskets are Teflon. The valve features four seats for equal seat loading, and ball to prevent excessive seat loading and reduce side loading on the stem. It also features a unique live-loaded cup-and-cone lower stem sealthrust bearing that separates the bearing and sealing functions, as well as a multiple upper stem seal.

Riding on our experience in the industry, we, as a Manufacturer, Supplier and Exporter have positioned us in the higher echelons of the industry. The 5/3 Way Hand Operated Manual Valve on offer is acknowledged among customers owing to its impeccable quality. Our distribution network allows us to facilitate quick and convenient delivery in a matter of time at your doorstep. Contact us to get it for cheaper rates.   Additional Information: Type: 5/2 Way hand operated manual valve Port Connection: 1/4" BSP Mounting: Independent Media: Air Operating Temperature: 80°C max Operating Pressure: 2-10 bar Orifice: 6 mm Valve Body Material: Aluminium alloy hard anodized

Designed and manufactured to eliminate fugitive emissions and to handle the toughest services such as:The stuffing box design with all the positive shutt-off, corrosion resisting features of other Weir BDK PTFE Sleeve Plug Valves

• Brand Name: Belimo,Honeywell,Siemens
• Power Source: Electricity
• IP Rating: IP54
• Nominal voltage: AC/DC 24 V
• Nominal Torque: 5 Nm
•  :

The SANKEY Series 1530L&T- is a versatile large size multi-port ball valve. It can be configured as a three-way valve with "L" or "T" ports. It consists of a heavy-duty centre section with bolted-on flanged ends for Class 150 flanges, Class 300 Flanges. All body gaskets are Teflon. The valve features four seats for equal seat loading, and ball to prevent excessive seat loading and reduce side loading on the stem. It also features a unique live-loaded cup-and-cone lower stem sealthrust bearing that separates the bearing and sealing functions, as well as a multiple upper stem seal.

• Brand Name: Mahavas Precision
• Features: Durable finish standard, Sturdy design , Tight binding.
• Body Materials: Carbon Steel (A216 Gr WCB) / Alloy Steel (A217 Gr WC6) / SS (CF 8M)
• Size: 25 NB to 200 NB
• Rating: ANSI Class 300 & higher on request
•  Leakage Class: ANSI B 16.104 CL IV

RUTCON Series 3230 Three Way Globe Control Valve is ideal for blending two separate flows, by having two inlets and a common outlet, or dividing a flow into two proportional parts by having one common inlet and two outlets. We are known as one of the leading Three Way Globe Control Valve Manufacturers, Exporters, and Suppliers in India. Our Three Way Globe Control Valve is offered at the market leading prices. Details Sizes : ½� to 8� (15mm to 200mm) Higher sizes available on requestRatings : ANSI B 16.5 150# and 600# other standards available on request Applications For high temperature fluid and particularly for textile industries, to mix or divert fluids Design & Performance Features High flow capacityHigh range abilityLeakage capability better than ANSI class IV & consistent with normal single seat valveLeak proof packing are available on requestOption of inner or outer seated design minimizes flow instabilityValve is used for mixing or diverting services depending on customers requirement

We offer Three Way Valves. For best control and on/off functions use our three way valves. We manufacture three-way control valves using the finest grade raw materials which ensures the unmatched quality and durability. Our three way valves are extensively used in all thermodynamic processes. They are ideal for saving the installation cost as the controller is pre-assembled on our valves. We have well positioned ourselves amid the reliable 3 way valves exporters & suppliers. Applications all thermodynamic processescooling system for motor shipsheating and cooling system for plate pressingvulcanizing benefits save installation cost : controller comes pre-assembled on the valvesaves loop cost: eliminates the need of separate sensor, transmitter, i/p controller and positionerlow maintenance.

We are primarily engaged in delivering quality assured Three Piece 3 Way Ball Valves to our clients. The Three Piece 3 Way Ball Valves are manufactured under the close supervision of our professionals. Clients can also get customized packaging of Three Piece 3 Way Ball Valve as per their requirements at affordable prices. Attributes Fire safeAnti- corrosiveSmooth functioning General Specification Sizes Available : 1/2" to 2 (DN 15 to DN 50)Temperature Rating : -60oF to450oFEnds : Screwed/Socket/ButtWeld Pressure Rating : #400 & # 600 - (IC. Castings)Reduce Pressure Rating : # 800 - (Forged Valve) Available Material Of Construction Body & Pipe End : CF8M, CF8, CF3M, WCB, A105, CF3, F304, F316, CN7MSeats & Seals : PTFE, RPTFE, Carbon Filled PTFE, S/S Filled PTFE, Grafoil Features Extra High Cycle Life Provided by Spherical Segment StemSelf-Adjusting Stem Seal Automatically Adjusts Seal to Compensate for Wear, Temperature, and Pressure FluctuationsBlow SotProof StemFull Port Construction Minimizes Pressure Drop Across PipelineAnt-Static Oevice Three-Piece Swing Out Design for In-LineMaintenanceISO 5211 Mounting Dimension for Easy AutomationDouble body seal feature to suitable for high pressureAir Cushioned Handle Sleeve for Confortable Manual Operation

3 way plug valve, Blind plug, Industrial plug valve, Lubricated Plug Valves

3 WAY PGP-UB Gauge Valve, Global Isolation Valves, MPV Gauge Valve
