application
used for water supply in residential bungalows, flats, hotels, garages, dairies and laundries.water circulation for fountains and solar heater systems.gardening and curing at civil works.used as suction booster in cities.ornamental sprinklers.
technical data.
model : ym-sw3
hp/kw : 1.50/1.10. Version : single phase, 160 – 240 volt (permanent split capacitor).
rpm : 2880 : frequency. 50hz. insulation class : b. duty type : s1 (continuous).
operating data.
duty point head : 40 meters. duty point discharge : 2600 lph.
suction lift : 8 meters. total head : 8 meters.
nominal pump size in mm : 25x25 (sucxdel).
maximum flow rate : 3.66 m³/hr / 61 lpm.
maximum operating pressure : 5.8 bar.
maximum liquid temperature : 45º c.
maximum ambient temperature : 65º c.
