Shiwkon Digitek Pvt. Ltd. Anand Nagar, Rajkot, Gujarat

  Bimetal temp. gauges are economical, rugged, reliable temp. measuring instruments. Dial Size : 63 mm(2.5"), 100 mm(4"),150 mm (6") Accuracy : +/- 1.6 % Stem : SS 304, SS 316, up to 300 mm Mounting : Bottom , Back, & every angle Connection : �� , 3/8" , �� ,BSP / NPT(Fix or Adj.) Temp. Range : -30 to 50 to 500� c Thermowells suitable for all temperature gauges Application   For computerised recording & printing data of Kiln temp. On line Profile recording for oven & muffle furn

  Infrared Thermometer measure the surface temperature of an object. It�s optics sense emitted, reflacted and transmitted energy which is collected & focused on a detector. It�s electronics translate information into a temperature reading which is displayed on the unit. Portable Thermometers are available in Different Temp. Range : -30 to 400� c, -20 to 600� c, 0 to 800� c, 0 to 1000� c, 0 to 1500� c, 200 to 1800� c, 600 to 3000� c Low cost Disappearing filament type oprical pyrometer are avaible in 700 to 3500� c range. Application   Use to measure surface temperature of any object, klin temp, Motor winding temp., Electrical Panel Switch Gear Temp.

Online temperature measuring system consists of Infrared Non Contact Temp. Sensor, object sensor, processing unit & extra large jumbo display Special design for fast & accurate temp. measurement of ceramic tiles. Infrared Sensor is activated only when object comes under it. Display shows temp. of only object. Models : SOT 54 : Temp. Indicating unit wih panel.SOT 63 : Temp. controlling unit with high & low set point.SOT 72 : control panel with buzzer for indication of high & low temp.  Application   For continous surface temperature measurement of object passing on process line

Thermocouple type ‘K’ (cromel alumel or Cr.Al or Ni.cr-Ni) are temperature upto 1000°C /1200°C maximum. Thermocouple type ‘J’ (iron-constantant or Fe-K) for temperature upto 800°C. Resistance Temperature Detector (RTD) type (PT-10, PT-50, PT-100, PT-200, PT-1000 & CU-53) to measure temperature from -400°C to 600°C. All sensors available in metalic protection sheath & Thermowell made of SS 304, SS 316, SS310, HRS 446, inconel 600/800 with insulation by ceramic beads,hand-filled mgo & MI .Application   For Preheating , Cooling zone of Roller&Tunnel kilns, Chimney, Hydralic, Press, Gasifier, Dryer,vessel, Deep freezer, Oven and Boiler.

Single pair to multipair armered/unarmered cable Insulation : PVC/PVC,Fiber glass /FG/SS(Shilded) , FG/FG/Asbestose,Teflon,Silicon Rubber,TRS etc. Conductor Size : 3/24 SWG , 3/26 SWG , 7/36,14/36 SWG etc. Heavy duty,rugged and easily available.   Application   Used to connect thermocouples & RTDs with Indicators & Controllers

We are brings forth a wide range of Automation Products like PLC, HMI, & SCADA,Photocell & Proximity Switch,Variable Frequency Drive (VFD) and more.

  Type �R� (Pt. Rh. 13% - Pt.) & Type �S� (Pt. Rh. 10% - Pt.) are used to measure temperature upto 1400�C/1600�C maximum. Type �B� (Pt. Rh 6% - Pt. Rh 30% or Pt. 18) are for temp. upto 1800�C max. Thermoelement pair is protected by two or three ceramic sheaths of various types depending upon working temperature and environmental conditions. Ceramic protection tube Type KER 610 - with 60%, 80%, Al2O3. Type KER 710 - recrystalised - high alumina tube with 99.9% Al2O3 available in 24mm, 20mm, 15mm, 12mm, 10mm, 8mm, 6mm dia. Holding tubes made of SS 304/SS 316 of 32mm, 25mm, 20mm dia are used to hold ceramic sheath with head. Steatite Ceramic terminal block with nickle plated terminals. Die cast Aluminium/S.S. mounting head & adjustable flange. Application   To measure temperature of firing zone of roller &Tunnel kilns,shuttle kilns,Hot zone of high temperature Furnaces

  Widest range of single/multi channel , linearised Temperature Indicators with micro controller chip with 0.5" , 1" , 2� , & 4" Display Digital on-off , Propostional , PD type temperature controllers with single/double set point having 5 Amp , 230 V AC relay output. Available in 48 X 96 mm2 , 72 X 72 mm2 , 96 X 96 mm2 , 96 X 192 mm2 size. Multichannel Temp. Scanner with 8 channel , 16 channel , 32 channel inputs Separate display for ch. No & temp., auto � manual switch and RS 485/RS 232 communication port. Application   For displaying temp. of thermocouples, RTDs. Controlling temperature of freezer,oven,vessel and Furnace.

  Fuzzy Logic PID Controllers with Universal Input (Thermocouple / RTD / 4 to 20 mA) Control Output : Servomotor, On-Off Relay, 4 to 20 mA Alarm Output : upto two alarm, 230 VAC, 3 Amp Relay Additional features : Remote set point, Retransmission output, Serial Communication RS 485/RS 232 Programmable profile controller with 16 segment Ramp �Sock program Size : 48 X 48 mm2, 48 X 96 mm2, 96 X 48 mm2, 96 X 96 mm2  Application   For Precise & fine controlling of temperature, pressure, level, flow and speed of motor through AC Drive

  Multi channel Data logger in universal fix type input with 8/16/32 channels Each Channel can store 3000 readings , 128 KB Capacity Parallel centronic port for direct printing RS 232 / 485 Serial port with modbus, RTD protocol PC Based Data Acquisition Software Historical Graph & online trend available. 24 Hrs. Format database available for excel report generation. Logged data is saved as different database System requirement : PIII, P4, 128/256 MB Ram 5 GB Hard disk Win 98/2000/Xp. 1 serial & parallel port, 1 CD-ROM , Color monitor(800 X 600)  Application   For computerised recording & printing data of Kiln temp. On line Profile recording for oven & muffle furn

Shiwkon is offers a wide range of level instruments like Vibrating Fork Level SwitchController & Capacitance, Conductivity & Flot operated Level Transmitter Switch etc.

We are offering pressure instruments which includes pressure transducers & differential pressure transmitters, digital portable pressure indicator, pressure gauges etc.

We are offering Temperature Instruments like high tempereature thermocouples, low temperature thermocouple etc.

We are offering flow instruments like electro magnetic flow meter,gas & air flow measurement and so on.
