Features
Semi-auto mode
Pure mechanical mode
Single or bi-directional function in mechanical and electrical versions
Automatic reset of barrier arms after each passage
Adjustable time out delay
Operating mode
Single passage in the set direction
Bi-directional passage
Free passage in the set direction
Always free or locked materials
Housing : ss304
Barrier arms : stainless steel
Lid (optional) : stainless steel or artificial stone(black / brown)
Secondary controller
Users : 30000 (rfid)
Fingerprint : 3000
Transaction storage : 100000
Integrated controller : inbio-260
Relay : 12 v relay for lock
Support fire alarm : yeTechnical Specifications
Passage width : 520mm
Throughput rate : 35 p/m
Power supply : 100 ~ 240V
Operational voltage : 24V
Max power consumption : 30 W
Frequency : 50 ~ 60hz
Protection level : IP44
Working temperature : -25°C ~ +70°C
Electro - magnetic drive : DC
Dimension excluding bar (in mm) : (L)480 x (W)280 x (H)980
Net weight including bar : 44kg
MCBF : 5 Million
