Xenon Test Chamber
5,000,000 - 10,000,000 / piece
Internal dimensions
950*950*850 mm
Overall dimensions
1300*1420*1800 mm
Specimen Capacity
42pcs
Specimen holder size
95*200mm
Irradiation Source
1 piece of 4500 W water-cooled Xenon Lamp with inner quartz and outer borosilicate filter
Irradiance Range
35 ~ 150 W/㎡
Bandwidth Measurement
300-420nm
Chamber Temperature Range
Ambient ~100℃±2°C
Black Panel Temperature
BPT 35 ~85℃±2°C
Relative Humidity Range
50~98% R.H±5% RH
Water Spray cycle
1~9999H59M, adjustable
Controller
Programmable color LCD touch screen controller, Multi-language interface, Ethernet , USB
UV Radiometer
Tolerance: ±5%
Heating system
Nichrome heater
Cooling system
Mechanical compression refrigeration system
Refrigerating unit
French TECUMSEH compressor
Humidification system
External isolation, stainless steel surface evaporation humidifier
Air circulation
Centrifugal wind fan
Water supply system
Automatic water supply; Water purification system
Safety device
Humidifier dry-combustion protection; over-temperature protection;
over-current protection; Refrigerant high-pressure protection; Water shortage protection,
Earth leakage protection;
Interior material
SUS304 stainless steel
Exterior material
Steel Plate with protective coating
Thermal insulation
Polyurethane foam
Observation window
Interior lighting , double-layer thermo stability silicone rubber sealing
Power Supply
AC380V 50HZ
Standard
ISO 105-B02/B04/B06, ISO4892-2, ISO11341. AATCC TM16, TM169, ASTM G155-1/155-4, JIS L0843, SAEJ1960/1885, JASOM346, PV1303, IEC61215, IEC62688
Description
Xenon arc chambers reproduce weathering damage by sunlight, temperature, humidity and water spray. Xenon weathering test chambers are utilized in textiles, dyes, leather, plastics, paints, coatings, automotive interior parts, electrotechnical products, color building materials. To perform weathering test, color fastness tests, aging test, hardening test, softening test, crack. Accelerated weathering test methods included ISO4892, ASTM G155-1/155-4, ISO 105-B02/B04/B06, ISO11341, AATCC TM16, TM169, , JIS L0843, SAEJ1960/1885, JASOM346, and many others.
XL-S-750 xenon weathering chambers can place 42 pieces of specimens, are upgrade to programmable controller and Ethernet access. Their reliable performance and low purchase price make these products very competitive.
Features
4500 W water-cooled Xenon arc lamp system
Total 42 pieces of specimens capacity
Measurement and control of Irradiance: 340nm, 420nm or 300-400 nm, 280-800nm
Measurement and control of Black Panel Temperature( BPT)
Measurement and control of Chamber Temperature
Measurement and control of Chamber relative humidity
Programmable color display touch screen controller
Ethernet & USB
Automatic water spraying system
Build-in water reservoir and automatic water supply
Large viewing window in door
Sample holders and casters are standard
Safety protection system
Country of Origin : India
Number Of Flower : Salt Spray Test Chamber
Certification : CE Certified, ISO 9001:2008
Application : Industrial Use
Country of Origin : 440V
Condition : New
Power : 6-9kw
Driven Type : Electric
Total Carbohydrate : 1year
Automation Grade : Automatic
Brand Name : PRIME
Power Supply : 440V 3P
