In Polypropylene Pleated Filter Cartridges, we use the very latest gradient density micro fiber media technology, to provide a combination of excellent micro ratings, high flow rates and high contaminant holding capacities. A special combination of polypropylene media with variation in the fiber diameter has created a gradient density matrix, ranging from open on the outside to finer on the inside, thereby providing a filter with in filter, which considerably increases contamination holding capacity & throughputs.All components used in the manufacturing are biologically safe, chemically inert, and meet FDA and other international quality requirements. Polypropylene offers an extremely broad chemical compatibility, making it suitable for many applications.Polypropylene Pleated Filter Cartridges are precisely manufactured for use in critical filtration applications within Pharmaceuticals, Biotech, Beverages, Brewing, Food, Dairy, Semiconductors, Water Treatment, and other demanding process industries.Features
All Polypropylene construction
Gradient density micron fiber media
Thermally welded construction
Non - fiber migration
Micron ratings from 0.1 to 40
High surface area more than 0.5 m2
Biologically safe and have wide compatibility
FDA approved filters
Absolute & nominal efficiency
Robust outer cage
Configuration
Double Open Type (DOE Type)
Code 7 F (226 O Ring Design)
Code 7 S (226 O Ring Design/flat)
Code 3 F (222 O Ring Design)
Code 3 S (222 O Ring Design/flat)
Construction
Filter Media: 100 % Melt blown micro denier Polypropylene fiber
Support Media: Polypropylene fiber
End Caps: High strength polypropylene
Inner Core: High strength polypropylene
Outer Core: High strength polypropylene
O Ring / Gaskets: EPDM / Buna N / Silicon Viton / Cotton with stainless steel core
Applications
Fine Chemicals and Pharmaceuticals
R.O. Pre filtration
Ophthalmic Liquids Oral Drugs
D.I. Water
Photographic Film & Paper
Biological Fluids
Anti-Halation Coatings
Emulsions
Gelatins Developer
Alcohols
Essential oils
Water lines
Chemicals
