1. Granite base of size L 600 X B 900 X T 30 mm2. 60 mm Tubular Structure with cross member3. Wrap around construction4. Front panel laser cut with top rim and Z-plates at bottom to lock joystick5. All three sides closed, bottom sheet to place controller, CPU and UPS; with exhaust fan.6. Front double door with handles and lock.7. Front pivot jointed heavy duty links with extended horizontal connecting profile and vertical 45 X 45 connecting profile, monitor bracket at top, keyboard and mouse tray at ~1000 mm height (newly introduced!).8. 65 X 65 mm AV pads at 10 places9. 4 No’s DLP3 (AV disc with adjustable screws) at Ground Level10. 4 No’s – 3” Wheel11. Cable manager in LH and rear side, drawing pouch in RH side12. Power strip in rear; Leveling Ball, Spanner 24/2713. Powder Coat, structure and joystick panel RAL 900214. Instrument sticker15. Overall dimensions: L 620 X B 1110 X H 767 (over granite base) mm16. Weight: kg17. Execution in wooden box
Note- GST and Freight Charges are not included.
