Crosby HG 225 Hook and Eye Turn Buckles
Get Price Quote
We offer crosby hg 225 hook and eye turn buckles.
meets the performancerequirements of federal specifications ff-t-79lb, type 1, form 1 - class 5,and astm f-1145, except for those provisions required of the contractor.
crosby turn buckle assembly combinations include: eye and eye, hook and hook, hook and eye, jaw and jaw & jaw and eye. End fittings are quenched and tempered, bodies heat treated by normalizing.crosby’s quenched and tempered end fittings are normalized bodies have enhanced impact properties for greater toughness at all temperatures. Hot dip galvanized.
hooks are forged with a greater cross sectional area that results in a strongerhook with better fatigue properties.
modified unj thread on end fittings for improved fatigue properties.
body has unc threads.
crosby hg 225 turnbuckle eyes are forged elongated, by design, to maximize easyattachment in system and minimize stress in the eye.
for turn buckle sizes 14" through 2-12", a shackle one size smaller can be reeved through eye.
forged jaw ends are fitted with bolts and nuts on sizes 14" - 58", andpins and cotter on sizes 34" - 2-34".
crosby hg 225 turn buckles recommended for straight or in-line pull only.
lock nuts available for all sizes.
typical hardness levels, tensile strengths and ductility properties are available for all sizes.
crosby hg 225 turnbuckles can be furnished proof tested or magnaflux inspected with certificates if requested at time of order.
crosby products meet or exceed all the requirements of asme b30.26including identification, ductility, design factor, proof load and temperaturerequirements.
importantly, crosby products meet other critical performancerequirements including fatigue life, impact properties and material traceability,not addressed by asme b30.26.
