CNC Router Dealers in Surat (9 products available)

• X-Y-Z Axis Movement: 1300mm x 2500mm x 200mm
• Repositioning Accuracy: 0.2mm
• X-Y Movement: German Rack & Pinion Transmission
• Z Movement: Tiwan HIWIN Ball screw
• Table Size: 1200mm x 2400mm
• Max Idling Speed: 35000 mm/min
• Max Cutting Speed: 25000 mm/min
• Working Voltage: 3Ø/380 V/50 Hz (7.5 HP)
• Spindle (Air Cooled Italian HSD Spindle): 4.5 KW, 0-18000 RPM
• Drive Motor: Stepper
• Command: G Code (*.tap)
• Computer Interface: USB
• Controls: DSP/NC-Studio
• Colet Type & Size: ER 32 (3mm, 6mm, 12mm)
• Work piece Holding: Manual T-Slot Clamping
• Dust Collecting Arrangement: Dust Collection System
• Electricity Consumption: 13 HP
• Weight: 1300 Kg approx

Standard features:  Working area: 1300mm*2500mm*200mm 3.5 kw air cooling spindle made in China T-slot PVC table (with Aluminium Profile) Linear Rail：HIWIN Linear Guide way made in Taiwan DSP controller system , Tool sensor, One set woodworking tools Original type 3 software, 1G U disk, Inverter：Taiwanse Delta Inverter Electronic Parts：German Schneider Electronic Spare Parts Switch：Japanese OMRON Switch Cable： Highly flexible towline-only Cable Imported fire-resistant double-sheathed.Could be bent 300 000 times Voltage: 3PH 380V 50HZ Package: plywood case   Option items   1 Change HIWIN Linear guide made in Taiwan to THK Linear guide made in Japan: 2 Oil mist cooling system: （suggest to add if engrave on metal） 3 Change the stepping motor to DELTA Servo motor: 4 Vacuum system with Chinese Vacuum pump,5.5 KW, 160 CBM/h   4.1 Type A: Vacuum table in Zones (for size 1325 machine): 4.2 Type B: T-slot vacuum table (for size 1325 machine) : 4.3 Change the Chinese vacuum pump to Germany Becker pump (please check the price with seller) 5 Change the Chinese spindle to Italian HSD Spindle   5.1 3.0 KW HSD: 5.2 4.5 KW HSD: 5.3 6.0 KW HSD: 6 Dust collect system   6.1 3.0 KW single bag: 6.2 -5.5 KW single bag: 7 Change DSP system to Ncstudio system   7.1 without handwheel, for Stepping motor machine : 7.2 with handwheel, for Stepping motor machine: 7.3 without handwheel, for Servo motor machine : 7.4 with handwheel, for Servo motor machine: 7.5 change the normal distributor box to distributor box that can hold computer: 8 Working area : 1500*3000mm / 2000*3000mm / 2000*4000mm (please check the price with seller) 9 If the voltage is not normal, please check whether is necessary to add the transformer and its price with the seller. 10 Z axis up to 300mm: 11 Change the plywood case package to wooden case with Fumigation certificate:   Features and Functions:   • This is a cost effective CNC Router which adopts high quality spare parts in the world. . • Fast speed and high efficiency. Engraving speed could be 15 m /min • High precision . Products without burr and with smooth bottom face and profile   Configuration   • Spindle：Paaram Air coolant spindle, NSK Bearing,Silicon Steel Sheet ( Option: Italian HSD Spindle.) • Inverter：Taiwanse Delta Inverter • Electronic Parts：German Schneider Electronic Spare Parts • Switch：Japanese OMRON Switch • Linear Rail：Taiwanese Square HIWIN Linear Rail • Cable：MAXICAM Highly flexible towline-only cable imported fire-resistant double-sheathed which could be bent 300 000 times .

Solid wood, soft wood, composite wood(OSB,MDF,LDF,etc.),Foam(EVA,Polystyrene,etc.), Plastic (ABS, Acrylic, PVC, etc.), veneer, Aluminium.etc.Whole steel workframe , 6mm thickness bed, 10 mm thickness gantry beam.High Rigidity, Yadopt durable driving by synchronizing wheel consist of belt and gear shaft. Big power sub-division motors keep stable moving, improve your working efficacy,Adopt Handheld DSP controller with fast working precision , easy operation, It will start the work automatically at the point from which the power cut off. More intelligent,Using quality sensor switch, improve the machine working safty,Adopt Chinese best quality Stepper drivers, supply 35mmin air run speed. Improve production.

• Application: Industrial

y=1.25m helical rack z= ø25*10mm  pitch  ball  screw  axis motor stepper / easy servo / servo drive system belt pully / planetary gear box linear guide rail 25 mm lm guide spindle type 3.5 / 4.5 / 6 kw ( air cooled ) 3.2 / 5.5 kw ( water cooled ) spindle rpm 18000 to 24000  max travel speed 30000 mm/min machine accurcy 100 micron cnc controllers dsp  weihong  nk 105 program  working command g-code lubrication auto / manual hand operated pump power supply 1ph 240v 50hz / 3ph 440v 50hz with neutral and earthing

We are dealing best cnc router supplying company.

cnc gas profile cutting machine

Cnc Lathe, advance router

Cnc Routers, Chenille Embroidery Machines, Rapier Loom, Water Jet Loom

Wood Carving Machine, printer filament, CNC Wood Lathe Machine
