Combination Spring Hanger
Get Price Quote
The combination spring hanger (50 mm) manufactured by us is demanded to be used for suspension of heavy rotating equipment that includes fan coil units, air handling units, ventilation fans, pipes large variable air volume boxes, and air ducts in mechanical rooms.
qualities
g.i. Steel frame with powder coated to 100 microns paint thickness (exceeding 1000 hours of salt spray test) neoprene component acts as effective acoustic barrierassurance of protection against noise transmissionmolded neoprene cup to prevent contact of metal and springcompensation of suspension rod misalignment of 30 degree arc in hanger designlocking rubber bush to prevent dislocation and centralize the spring effective isolationspring diameter ensuring prevention from buckling of spring even when fully loadedpowder coated springs with appropriate color coding for easy identification
selection
point load including all variables like weight of water in pipe lines and others
specifications
isolator modelrated load (kg)spring coloursdimensions (mm)lwsf*rfhdscsh50-b2525green776011846215m12scsh50-b5050redscsh50-b7575blackscsh50-b100100yellowscsh50-b150150bluescsh50-c200200green948012773270m16scsh50-c250250redscsh50-c300300black948013573270m16scsh50-c400400yellowscsh50-c500500blackgreenscsh50-c600600yellowgreenscsh50-g700700black1079516373315m20scsh50-g800800yellowscsh50-g10001000bluescsh50-g12001200bluegreen1079516373335m24scsh50-g14001400bluebrown
