Environmental operating conditions0°C to 40°C, 0% to 90% RH (non-condensing)
Specifications valid in environmental conditions13°C … 25°C
Input (CaLsys -35/200 Autocal)Four Channels (One master and three test sensors), high-quality LEMO connector suitable for both T/C
CALsys -35/200 is a Highly Stable Stirred Liquid Bath for Calibration RTD / Thermocouple and also for compensation of cold junction.CALsys -35/200 offers the temperature range of -35 to 200°C. It has large tank which is filled with liquid (Water+Methanol/Silicon Oil). The liquid is heated or cooled to the desired temperature, where Methanol+Water are used for Negative Temperature and Silicon Oil is for Heating purpose.It has better stability & uniformity than dry block bath and as it uses of stirred liquid. This CALsys -35/200 is built using CFC-free refrigerants.Key Features:
High Accuracy
High Stability and Uniformity
Wide Temperature Range
PC Interfacing
Simple to Use and Cost-Effective
AccessoriesStandard Accessories
Reference Standard PRT…Part No.TPRT-A-300
NABL accredited calibration certificate - 3 point
Software - Including for setting bath temperature and monitoring the PV. Graphical representations of PV/TIME.
Operational Manual
Optional Accessories
Methanol............10 Ltr. No.(3050-M)
Silicon Oil............10L Part No.C200S-LB SO
Input (CaLsys -35/200 Autocal): Four Channels (One master and three test sensors), high-quality LEMO connector suitable for both T/C and Rtd.Software (CaLsys -35/200 Autocal): The calibrator will be provided with software for data recording (Manual Mode) and report generation in Auto Mode.Data Logging (CaLsys -35/200 Autocal): Data Logging facility with logged data export to the computer through LAN port (Optional USB)
