RF Micro Card Based Access Control System
Get Price Quote
Computerized Attendance Recording and Access Control system RF Micro, uses RF (Proximity) or Smart card. Contact-less Cards having card read range of 80 mm to 100 mm. User does not have to Swipe / Drop the card, just show the card.
Compact Design, ABS housing
Up to 22,000 punch storage capacity.
Up to 2000 employees database can be stored with employee name
8 digits card number (Standard)
128 x 64 LCD display for Date, Time, Employee Name, Card Number, Scrolling Message etc.
Useful for Access Control
Employees can be restricted to punch in particular Attendance Recorder
For Access Control, output for Lock, Door Monitoring, for Exit option of External Reader OR Switch
Programmable IN / OUT setting
Programmable 16 different reason cards
Up to 32 terminal Networking
Networking through RS 485 or optional TCP/IP
Switch Mode Power Supply (SMPS)
Optional Features
Contact-less RF or Smart Card
External Reader : with 128 x 64 LCD for separate IN / OUT or Access Control
UPS for full operation except Lock
Connectivity through TCP/IP for transferring data from remote locations
On-line Transfer
Proven software for all needs - for less than 10 employees to more than 5000 employees
User friendly Transfer and MIS software
Different software for Offices (without night shifts) and Factories having night shift
Communication : TCP-IP Converter / MMC Card
UPS : For full operation (except Lock)
External Reader : For separate IN / OUT punch OR for Access Control
