Polymech Plast Machines Ltd. Makarpura, Vadodara, Gujarat

Clamp Robust Integrated Casted Five Point Twin Toggle Clamping System T-slot For Easy Mould Change-Over Robust Box Type Moving Platen Withstand at High Injection Pressure Automatic Mould Height And Tonnage Built-Up System Five Stage Closing / Four Stage Opening Speed Setting Accurate And Sensitive Low Pressure Mould Safety Faster Clamping Operations With Precision Position Control  For Robot Interface / IML Clamp Monitoring Through High Response Proportional Valve Linear Transducer For Accurate Clamp Position Centralized Automatic Lubricating System (Grease Based) Core Pulling System (Single Cylinder) Hydro Electrical Guard Safety Ejector Knock Out Bar Multi-Point Programmable Hydraulic Ejector (Two Stage Position) Pulse Setting Ejector Operation Ejector Retract Position Sensing Safety Air Ejector System For The Both Halves   Injection Accumulator Based Accumulator Assisted High Speed Injection Injection Close  Loop Controls With State of The Art High Performance Proportional Valve  Control Very High Injection Efficiency Supported With LM Guide Smooth Motions Technology Multi Stage Variable Injection Pressure & Speed Profile Two Stage Variable Pressure / Speed Hold On Position Injection Profile For Monitoring Injection Function Radial Piston Hydro Motor Three Stage Variable Pressure / Speed For Refilling Digital RPM Indicator System Linear Scale For Accurate Injection Position Control Suck Back (Before /After Refilling) Semi-Auto Purging Program Intrusion Molding Program / Flow Moulding Sprue Break With Timer Lubricating System For Injection (Grease Based - Manual) Sealed Nozzle Tip Heater Back Pressure Control (Through PLC - Digital)   Hydraulic Energy Efficient Servo Drive System Single Module Pump Motor Mounting Base For Easy Maintenance Alarm For High Oil Temperature Appropriate Placement / Indication For Hydraulic Valves - Easy Approach Return Line Oil Filter with Clogging Indicator

Clamping Unit Integrated Casted Vertical Five Point Double Toggle System T-Slot - Drilling Taping for Mold Clamp Three Stage Mould Open/Close Speed Sensitive Low Pressure Mould Safety Linear Scale For Position Based Functions Motorized Mould Height Adjustment With Auto Tonnage Built up Guard Safety Hydraulic Ejector System (Linear Scale based - Multi Points - Multi Stroke) Centralized Auto Lubrication System ( Grease Based ) Air Ejector System ( Both Halves ) Core Pulling (Single Cylinder) Core Pulling Provision ( For Second Cylinder) Injection Unit Twin Cylinder Balanced Injection Unit Five Stage Reduced Injection Pressure System Linear Scale For Position Based Functions Five Stage Reduced Injection Speed System Auto Reciprocating Injection Unit Suck Back System Heating Insulation Cover Injection Hold On System Radial Piston Hydro Motor Back Pressure Control (Manual)

Features Larger Distance Between Tie Bar Larger Ejector Stroke with High Force Ejector Retract Confirmation Position Based Screw Profile for PET Processing High Torque Radial Piston Hydro motor Variable Displacement Volume Pump Benefits Fascinate To Accommodate Bigger Size Moulds Smooth Ejection Of Larger Length Of Preforms Ensure Mould Safety Homogeneous Mixing at Lower Melt Temperature High Plasticizing Rates At Low Torque Low Power Consumption

FA Type Microprocessor Taiwan Make Electro Proportional Hyd. System Core Pulling System. Single Cylinder Air Ejection System Moving and fix platen Auto Grease Lubrication System T-slot system for mold mounting Hallow Structure design for platen Integrated H-plate design Integrated Five Points Double Toggle system Five point Hydraulic Ejector System Sensitive Low Pressure Mould Safety Ceramic Heater Oil Temperature Indicator with interlock system Linear Scale for Injection, locking and ejection Twin cylinder injection System Motorized Mold height Adjustment (Proxi base) Audio Visual Alarm Electrical & Mechanical Guard Safety

Clamping Unit Integrated casted five point double toggle system T-Slot for mold clamping (70 T & Above) Three stage mould open/close speed Sensitive low pressure mould safety Injection Unit Five stage reduced injection pressure system Five stage reduced injection speed system Auto receprocating injection unit Suck back system Heating insulation cover Injection hold on system Radial piston hydro motor Back pressure control (Manual)

Programmable Logical Controller-Colour Monitor Energy Saving Electro Proportional Hydraulic System Festo Pneumatics A.c. Variable Frequency Drive High RPM Three Phase Blowers Linear Scale For Carriage Cylinder Movements Audio Visual Alarm Hook For Clamping Unit Single Piece Casted Top Blowing Assembly Super Finish Tie-bars For Smooth Movements Arrow Cutting Pressure Switch For Accurate Clamping Tonnage Hot Cutting Device (five Ltrs. And Above) "helical Gear Box Three Stage Parison Programmer (two Ltrs. And Above) Stretching Unit With Blowing Attachment (five Ltrs. And Above) Guard Safety (electrical)
