Coding Machine Dealers

To mark variable information like Batch No., Date Of Manufacturing, Exp. Date, Name & Address Of Consignor, Consignee, Product NameCode, Shipping Marks, Nett Weight, Gross Weight Etc., on porous (absorbent) & non-porous (non-absorbent) surfaces.

Technical specification printing area 50 mm. X 65 mm. Printing speed 25 36 48 stroke per min. Composing material metal & rubber stereo drive motor 1 phase.0.25 h.p, 1440 r.p.m. Overall dimensions (l) 650mm x (w) 475mm x (h) 275 mm weight @ 48 kg. Dimension after pkg. (l) 30" x (w) 24" x (h) 15" wt after packing @ 65 kg. Extra facilities * side & back stopper is provided for margin setting for large labels cartonspouches, extension platform support with side stoppers provided.

Advance Features 1. XAAR printhead from UK assure the print quality.2. One key Start up and shutdown, simple ink cartridge replacement. Sealed ink supply system without any leakage.3. Low cost, no need of solvent.4. Can print both dot-matrix font and normal font.5. Can install all kind of character fonts freely from USB.6. Environmentally friendly ink, non-toxic, will not pollute the substrates. Suitable for pharmaceutical, food, beverage factory.7. Can generate dynamic barcode and 2-D barcode, can print random code.8. Touch screen, powerful function, easy operation.9. Carton size: 62*45*25CM Weight: 15KG. Advanced Capabilities Mobile phone Display screen, Beverage Cap, Food Packages, Pharmaceutical Packages, plastic door/window, Aluminum alloy door/window, Battery, Plastic Sheet, Plastic pipe, Steel Sheet, Printed circuit board, Chip, Woven bag, Egg, Braking Pad, Mobile phone shell, Carton, Motor, Transformer, Plasterboard, External Packages etc Material of SubstratesMetal, Plastic, Wood, Aluminum foil, Paper, PE bag, Glass etc. Matching Equipment Conveyer Belt:The standard size is L1500mm*H75mm*W30mm, the width of the belt is 20MM. The Conveyer belt specification can be design according to customers' requirements.Paging Machine:The paging machine is used to separate the piles of paper, cartons or packaging bags into single piece automatically and send them to the conveyor belt for Ink Jet Printing. It eliminates the inconvenience of manual separating, and makes full use of the advantage of high-speed jet printing, thus improving the work efficiency of jet printing. It can count automatically, or set the number of pages and stop automatically. The specification can be design according to customers' requirements.Winder for roll packed Pressure sensitive label & paper:It is suitable for roll packed label or paper. The printing speed can reach 15,000 pcs per hour when it works with our PRIMA P1 Small Character Ink Jet Printer. Rotating Table for Energy Saving Lamp:As the shape of the Energy Saving Lamp is round and the Rotating table can help us to print a circle to assure the printing quality. This table can also test the quality of the lamp at the same time.

Line Speed Capability Upto 482 fpm (150 mmin) for 1-3 lineprinting (10 character inch, single line printing). Font Matrix Configuration Single-line: 5x5, 5x7, 7x9, 12x16, 16x16 (Chinese Character) Double-line: 5x5, 5x7 Nominal Character Height Selectable from 0.079” (2 mm) to 0.295” (7.5 mm), depending on font

Printing Area:50 mm. x 65 mm.Output:10 to 15 labelscartonspouchesmin. manually. Composing material:Metal & Rubber Stereo. Overall Dimensions:375 x 175 x 200 mm, Weight:@ 7.5 kg.Extra Facilities:Side & Back Stopper is provided for margin setting for large Labels CartonsPouches, Extension Platform support with side stoppers Provided.

  Flexography India Press is a Global Manufacturer & Exporter of flexo photo polymer plate making machine, Rubber stamp making machine, Solvent Recovery Equipment…etc. for Flexographic  printing industries…FIP Group’s Head quarter in the Viramgam and Manufacturing plant in Ahmedabad, Gujarat,India.       Currently, we are  manufacturing Flexography photopolymer plate making Equipment, including Rubber Stamp  Making Equipment, Letterpress Plate Making Equipment, pad printing photo polymer plate making equipment, Label photo polymer plate making equipment , Varnish photo polymer plate making equipment,  Flexo Solvent Recycling unit, Liquid  Resin Stamp making  equipment, Nylon Block making equipment , Water Wash photo polymer plate making equipment , Flexo plate making equipment, Flexo photo polymer plate making machine All type of stamp making series , Embossing plate making equipment, Pharmaceutical Batch plate making equipment, Woven sack photo polymer plate making equipment, flexo photo polymer die making machine , flexo photo polymer block making machine , photo polymer batch coding machine , flexo stereo photo polymer plate making machine , and all type photo polymer plate making machine series …….for flexographic

We are engaged in made and supplying superior quality roll to roll batch printing machine. We are highly specialised in fulfilling custom requirements of Flexible Packaging for domestic and global markets.

  Features: FAST , RELIABLE AND MULTIPLE LINE CODING Ideal for high speed production lines. It delivers high quality codes at production speeds of more than 200 impression / minute with multiple line code printing. Easy, Simple, Affordable The innovating structure has an excellent behaviour in energy & cost saving. Fully automatic carton feeding unit with easy & quick adjustment. Sharp & precise printing control Totally enclosed construction with parts of S.S. and sintered bronze for long life operation of coder. Machine working: It is electro mechanical fully automatic high speed coding system. Once stacks the labels / cartons in order on sloping plane tray (Dispenser) for feeding. It’s automatically picked up by rubber friction insert, fed to printing one by one via guide track. This system is similar to rotary letter press. Oscillating roller and dispersing an ink of even film thickness to inking roller and inking roller transfers ink to stereotype, finally image transfer to the substrate. This cycle is continuously running at high speed with clear & sharp impressions.

This EMCC Coder is used by manufacturerspackers to printcode statutory information’s such as B.No, Dt of Mfg., Expiry Date, Prices & other information’s on various packings, containers, labels, cartons, pouches of etc. It has been specially designed to be user friendly, low maintenance, and to work on universal packaging surface. This excellent coder replaces manual roller coders, labor-intensive marking systems, self-inking coding devices and other conventional machines. It is used in industries such as Pharmaceutical, food & Beverage, surgical, spices, plywood.automobiles,oil, dairies and etc. It is available in two different models and can easily print up to 4-6 lines of printing on various packed goods.Suitable for all manual & automatic coding on various packing.

Contact CoderContact Coder having Ink Roller or Ink Chartridge system to print message with help of rubber stereos suitable for sticker labelling machine.
