Applications :
Food & Beverages Industries
Dairy Industries
Pharmaceutical Industries
Paint& Color Industries
Chemical & Textile Industries
The suction and delivery connection are available in 1/4 to 2 ½” size. These Gear Pumps can be operated up to pressure of 10 kg/cm² with 8.33 LPM to 300 LPM flow capacity and has suction lift of 1m to 5m at rated speed of 1440 RPM. These pumps are designed up to maximum Viscosity of 1, 00,000 SSU and maximum temperature up to 200ºc
Technical Features :
Complete S.S.- 316 M.O.C
Nitrided Gears & Shaft For Longer Life
PTFE Coated DU Bush For Smooth Perf romance
Zero Leakage PTFE type Z- Pack Sealant In Gland
Compact & Simple In Design, High In efficiency
Applications :
Food & Beverages Industries
Dairy Industries
Pharmaceutical Industries
Paint& Color Industries
Chemical & Textile Industries
The suction and delivery connection are available in 1/4 to 2 ½” size. These Gear Pumps can be operated up to pressure of 10 kg/cm² with 8.33 LPM to 300 LPM flow capacity and has suction lift of 1m to 5m at rated speed of 1440 RPM. These pumps are designed up to maximum Viscosity of 1, 00,000 SSU and maximum temperature up to 200ºc
Technical Features :
Complete S.S.- 316 M.O.C
Nitrided Gears & Shaft For Longer Life
PTFE Coated DU Bush For Smooth Perf romance
Zero Leakage PTFE type Z- Pack Sealant In Gland
Compact & Simple In Design, High In efficiency
INTERNAL POWER LOSSESThe internal power losses in rotary pumps are of two types the mechanical losses is the power necessary to overcome frictional drag of all the moving part withing the pump while viscous losses id power required to overcome liquid viscous drag & shearing action of the fluid. this can be computed from the graph on the opposite sideH.P CALCULATIONThe break horse power required to drive a rotary pump is sum of the theoretical hp & internal losses. the theoretical horse power is the actual work done is moving the fluid from inlet port to out let pressure condition & is product of constant C=0.037,Capacity in cub. Mt/hr. & pressure Kg/Sq. Cm or constant C=2.39,Capacity is us G.P.M. & Pressure in PSIPUMP SELECTION & USESThe bush bearing type of pump can be used for clean viscous liquid having sufficient lubricating Value such as clean lube oil vegetable oil, Fish & Animal oil, Gear oil, Glycerine, Hydraulic oil for intermittent duty. However for continues duty pump with needle roller bearing in SI Series should be selected for liquid having low viscosity poor lubricating values of containing dirts or impurities Such as asphalt bitumen Furnace oil tar, Cellulose, Starch LSHS, HPS, Molasses Napthia, Phenol resin, RFO, Silicate Soap Solution Viscous wax etc.INSPECTION AND TESTINGAll pumps are individually tested for its performance as per JIS B- 8312- 1976
INTERNAL POWER LOSSESThe internal power losses in rotary pumps are of two types the mechanical losses is the power necessary to overcome frictional drag of all the moving part withing the pump while viscous losses id power required to overcome liquid viscous drag & shearing action of the fluid. this can be computed from the graph on the opposite sideH.P CALCULATIONThe break horse power required to drive a rotary pump is sum of the theoretical hp & internal losses. the theoretical horse power is the actual work done is moving the fluid from inlet port to out let pressure condition & is product of constant C=0.037,Capacity in cub. Mt/hr. & pressure Kg/Sq. Cm or constant C=2.39,Capacity is us G.P.M. & Pressure in PSIPUMP SELECTION & USESThe bush bearing type of pump can be used for clean viscous liquid having sufficient lubricating Value such as clean lube oil vegetable oil, Fish & Animal oil, Gear oil, Glycerine, Hydraulic oil for intermittent duty. However for continues duty pump with needle roller bearing in SI Series should be selected for liquid having low viscosity poor lubricating values of containing dirts or impurities Such as asphalt bitumen Furnace oil tar, Cellulose, Starch LSHS, HPS, Molasses Napthia, Phenol resin, RFO, Silicate Soap Solution Viscous wax etc.INSPECTION AND TESTINGAll pumps are individually tested for its performance as per JIS B- 8312- 1976
FeatureGear & shaft of alloy steel & heart treated
Country of OriginIndia
CapacityUp to 6000 LPH
Speed1400 rpm & 2880 rpm
Size1” BSP Screw End Suction
Application :
Pumps most suitable for road construction machinery.
Boilers, Oil burner, Hydraulic Drive.
Pressure and transfer pump.
Booster pump for diesel locomotive.
Pump for forced feed lubrication.
Filter Pumping
Pump for lubrication oil and hydraulic oil.
Pump suitable for LDO, FO, HSD & LSHS
Instruction:
For trouble free of pump following points are to be considered carefully-
True alignment while mounting pump
No any water particle allowed with oil
Application :
Non lubricant liquid should not be used
keep direction of rotation of pump and suction and delivery connection as
shown on pump (R= Clock Wise, L= Anticlockwise viewed from shaft end)
They should not be need for handling abrasive or corrosive or liquid with solid mater.
General Specification : "PARAS" Fuel Injection Gear Pumps are positive displacement gear pumps. Available with without built in pressure relief valve. Pimps are of High Pressure and Internal Lunrication system is so design ed that the liquid running through the pump acts as a lubricant. Pumps are designed for wide range of applications. They should not be used for handling abrasive liquids with solid matter. Pumps are self priming and give maximum vaccum of 610-660 mm of Hg. They can handle non-corrosive and non abrasive liquids of maximum vicosity of 455 cents-stocks(CS) and temperature 200 degree celcius.Salient Features :
Due to static 'O' Ring there is no leakage.
Low cost maintenance.
Rotors & Gears are used with hardend and ground which gives good efficiency and more durability.
We have specially provided enough lubrication system to oil seal, which increase the life of oil seal.
Available with or without built in pressure relief valve and external bypass.
We have also developed pump suitable for Kerosean
We try our best to fulfill customer's requirements and delivery as fast as possible.
Application :
Pumps most suitable for road construction machinery.
Boilers, Oil burner, Hydraulic Drive.
Pressure and transfer pump.
Booster pump for diesel locomotive.
Pump for forced feed lubrication.
Filter Pumping
Pump for lubrication oil and hydraulic oil.
Pump suitable for LDO, FO, HSD & LSHS
Instruction:
For trouble free of pump following points are to be considered carefully-
True alignment while mounting pump
No any water particle allowed with oil
Application :
Non lubricant liquid should not be used
keep direction of rotation of pump and suction and delivery connection as
shown on pump (R= Clock Wise, L= Anticlockwise viewed from shaft end)
They should not be need for handling abrasive or corrosive or liquid with solid mater.
General Specification : "PARAS" Fuel Injection Gear Pumps are positive displacement gear pumps. Available with without built in pressure relief valve. Pimps are of High Pressure and Internal Lunrication system is so design ed that the liquid running through the pump acts as a lubricant. Pumps are designed for wide range of applications. They should not be used for handling abrasive liquids with solid matter. Pumps are self priming and give maximum vaccum of 610-660 mm of Hg. They can handle non-corrosive and non abrasive liquids of maximum vicosity of 455 cents-stocks(CS) and temperature 200 degree celcius.Salient Features :
Due to static 'O' Ring there is no leakage.
Low cost maintenance.
Rotors & Gears are used with hardend and ground which gives good efficiency and more durability.
We have specially provided enough lubrication system to oil seal, which increase the life of oil seal.
Available with or without built in pressure relief valve and external bypass.
We have also developed pump suitable for Kerosean
We try our best to fulfill customer's requirements and delivery as fast as possible.
