Daliya Making Machines
Get Price Quote
Description of Dalia Making MachineCracked wheat or daliya is used to make a nutritious dish at breakfast or whenever a light meal is required. It can be made sweet or salty according to taste. The wheat is boiled in a little water and cooked till it becomes soft and the water evaporates. Sugar and milk may be added to the cooked wheat or it can be seasoned with salt, pepper and butter before serving.We have for our client commercial dalia machine that have fully machined & balanced beater. These commercial daliya machines are popular for continuous crushing and suitable for making daliya. Offered in compact size commercial daliya machines do not require too much space.
Key features of dalia making machine
Unique and reliable design of the dalia making machines series pulverizers are highly effective as well as nonstop continuous pulverizing process.
All contacting parts are non corrosive materials.
All rotating parts are dynamical balanced for less vibration and higher performances.
Low temperature grinding technology thus the original ingredient cannot destroy.
Ideal for dry crushing
Increased production leading to faster return on the investments
Hardened and fully machined shelving type beater thus less wear and tear.
Single pieces grinding chamber no separate joints of fabrication for out late.
Operating principle of dalia making machinery
The flow of material from the feeding hopper is regulating by means of side handle easily to suit the load. Rotor runs in anti-clockwise direction. The beater pass just beneath the ratchet teeth liner fitted inside the top half of the crushing chamber, leaving a suitable gap between the liner teeth and the tips of the rotating beater. This cuts the material caught between the liner teeth like a sword with a scissors action at a 450/650 RPM. After the required size reduction, the material will pass through the screen fitted inside the lower discharge end of the grinding chamber. No sieving is required, as the appropriate size screen fitted will not allow coarser material to pass through. The air generated in the crushing chamber forces the powder to pass through the screen fitted at the bottom discharge end of the crushing chamber, into a filter attached to the delivery trough below. (When crushing wet-pulpy materials, the balloon should not be use)
Servicing guidelines of dalia making machinery
Open the cover of chamber all grinding parts cleaned with a brush in couple of minute and the pulverizer is ready for next grinding. If required, the grinding chamber can also washed with water. Remove the cotton balloon and the screen, close the cover tightly and start the grinder. Now pour a bucket or two of water into the hopper. The grinding parts will be flushed with the water and cleaned. Continue running the machine for a few more minutes as the draft of the fresh air sucked into the grinder will dry it. Please check the oil level of oil bath chamber regularly.
Standard accessories of dalia making machinery
Three set of perforated round holes screens
Easy movable hopper helps you to ensure continuous and steady feed to the machine. Very useful where feed material is to be manually dumped from bags
Motor pulley
One numbers of cotton balloon.
Mid steel fabricated foundation plate with adjustable rail for motor.
Extra accessories of dalia making machinery
Suitable totally enclosed fan cooled single or three phase squirrel cage motor as per is: 325 or 996 is supplied with mono pulverizer {electricity (special power can be accommodated): 110/220/380/415 volts, 50/60 Hz, 1/3 phase }
Suitable miniature circuit breaker as per is: 8828 with 3 meter cable and 3 pin top as per is: 1293 are supplied with daliya machine as extra cost or 3 meter 4 core cable, starter, ampere meter, and capacitor, are supplied with daliya machine at extra cost.
All contacting parts stainless steel 304 / 316 can be accommodated
Application of dalia making machinery
The techno wings daliya making pulverizer are used for a producing dalia of wheat (broken wheat for wheat porridge, dalia), maize daliya. maize grits, corn grits, etc..
Construction of dalia making machinery
Commercial dalia machine is made from heavy duty cast iron base. Cast iron oil chamber housings are for long life of bearings. Aluminium grinding chamber lined with serrated stainless steel plates, which protects the body from wear and tear. Grinding done by a set of stainless fixed better on a balanced rotor. A screen classifier forms the lower half of the grinding chamber.Due to continuous improvements, we reserve the rights to alter and/or amend dimensions/design without prior notice.
The figure for capacities given are for guideline only may very force case to case and depending many factors.
