Profile Projector Dealers in Hsidc Industrial Estate, Ambala

We offers a Wide Range of Profile Projector from DRO / Data Processor based to Software Based systems is available in Vertical and Horizontal light Source . All projectors are equipped with contour and surface illumination. Magnification Range upto 100X & Screen Dia 150mm to 600mm.

It is a compact model (Bench Type) profile projector suitable for all types of measurements and inspections at industries and engineering colleges. Antiglare hard glass Screen 200mm DIA with cross rotatable through 360 degree with least count 1 minutes an arc. Provided with X-Y movement of 120mm x 120mm measuring stage, travel 50 x 50 mm with the elp of a slip gauge, equipped with zero adjustment Micrometers of 25mm graduation having least count 0.001 mm. Supplied with high resolution 10x objective as standard and 20x or 50x or 100x as optional at extra cost. Equipped with built in counter illumination of 24 V 150 W halogen lamp and surface illumination system is a set of two halogen lamps (6V/20W) with a clamping device.

Advanced technocracy inc. Is manufacturer, exporter & supplier of profile projector. Having 200mm dia rotatable screen with vernier reading of 1 minute scale. Halogen bulb (12v 100w) with solid state variable light control built in transformer workable on 220v ac main. Stage x-y movement on ball bearing slides. Having micrometer (50mm dia) l.c.01 or 0.005mm fixed magnification 10x or 20x. Having transmitted light in card board box.

We Offer Profile Projector. For Accurate Magnification, Maximum Luminosity, Great Contrast, Uniform Resolution to the Edge of the Screen, Freedom from Distortion of the Images. It is Supplied with Standard Lenses with Magnification 25x and 50x for Contour Projection. The Maximum Visible Part of the Object On the Screen are 112mm and 5.6mm Respectively. The Screen Size is 330mmx380mm (13"x15"). The Maximum Diameter and Length of Work Accommodated On the Stage are 40mm X 150mm Respectively. It is Having Wooden Storing Cabinet with Lock and Key for Safe Custody of Lenses Etc. The Height and Weight of the Instrument is Approximately 1448mm (4'-9") and 68 Kg Respectively Optional Available Magnification 10x.

For accurate magnification, maximum luminosity, great contrast, uniform resolution to the edge of the screen, freedom from distortion of the images. It is supplied with standard lenses with magnification 25x and 50x for contour projection. The maximum visible part of the object on the screen are 11.2mm and 5.6mm respectively. The screen size is 330mmx380mm (13"x15"). The maximum diameter and length of work accommodated on the stage are 40mm x 150mm respectively. It is having wooden storing cabinet with lock and key for safe custody of lenses etc. The height and weight of the instrument is approximately 1448mm (4'-9") and 68 kg respectively optional available magnification 10x.

We are offering profile projector.a profile projector is an optical instrument that can be used for measuring. It is a useful item in a small parts machine shop or production line for the quality control inspection team. the projector magnifies the profile of the specimen, and displays this on the built-in projection screen. On this screen there is typically a grid that can be rotated 360 degrees so the x-y axis of the screen can be aligned with a straight edge of the machined part to examine or measure. having 300mm dia rotatable screen with vernier reading of 1 minute scale. Halogen bulb (12v 100w) with solid state variable light control built in transformer workable on 220v ac main. Stage x-y movement on ball bearing slides. Having micrometer (50mm dia) l.c.01 or 0.005mm fixed magnification 10x or 20x. Having transmitted light in card board box. optional accessories: graduated rotatable stage for angle measurement

We are one of the prominent Suppliers of Profile Projector that features a standard bench type with magnification of 10x & 20x, angular ring with L.C. 1-min. of an arc with cross hair line (of 0.2mm thickness). Our Profile Projector provides 0-50 mm stroke on work table with manual micrometer of L.C.-0.010/0.005 mm and contour illumination of 24v/150w. It has surface illumination of dual 12v/100w and 120mm focusing. Our clients can obtain bulk quantities of Profile Projector at reasonable price from us.
