Flow Switches Dealers in Bangalore

The Thermal Flow Switch Monitor SP-150 is based on the principle of thermal dispersion. A typical configuration uses two Temperature Detectors set within the tip of the sensor. One Temperature Detector is heated a few degrees above the other one. As the process medium flows over the tip of the sensor it disperses some of the heat from the heated Temperature Detector. The delta temperature is a function of flow velocity and converted into electronic signal. The open collector changes state once the set point has been reached.

The general purpose gas flow switch is a great choice for a broad range of relatively clean gases with non-coating characteristics. Media examples include nitrogen and scrubber exhaust fumes. The 1A relay provides a reliable switch interface with remote devices such as a PLC, SCADA or alarm. The short sensor is intended for use in pipe or ducting from 12” to 1-12”; the long sensor is applied in 2” and up. The switch set point may be adjusted from 1 to 90 fps. The product is broadly selected for low or no-flow applications.

Flow Switches, Centralised Lubrication Systems, Oil Filter
