PIR Sensor Module Dealers in Bangalore

Barometric Pressure Sensor Module

Get Price Quote

The BMP085 is the fully pin- and function compatible successor of the SMD500, a new generation of high precision digital pressure sensors for consumer applications. The universal C-code SMD500/BMP085 (?BMP085_SMD500_API?) is fully upward compatible to SMD500 and recognizes automatically the device ID. The ultra-low power, low voltage electronics of the BMP085 is optimized for use in mobile phones, PDAs, GPS navigation devices and outdoor equipment. With a low altitude noise of merely 0.25m at fast conversion time, the BMP085 offers superior performance. The I2C interface allows for easy system integration with a microcontroller. The BMP085 is based on piezo-resistive technology for EMC robustness, high accuracy and linearity as well as long term stability. Key features Pressure range: 300 … 1100hPa (+9000m … -500m above sea level) Supply voltage: 1.8 … 3.6V (VDDA) and 1.62V … 3.6V (VDDD) Low power: 5?A at 1 sample / sec. in standard mode Low noise: 0.06hPa (0.5m) in ultra low power mode 0.03hPa (0.25m) ultra high resolution mode < 0.1m possible with software averaging algorithm – Temperature measurement included – I2C interface – Fully calibrated New features Smaller package height 1.2mm Faster conversion time (standard mode each) 7.5ms (max.) Faster I2C data transfer max. 3.4MHz max. Extended min. supply voltage min. 1.8V min. Lower stand-by current (typ.) 0.1?A External clock not necessary Typical applications ? Enhancement of GPS navigation (dead-reckoning, slope detection, etc.) ? In- and out-door navigation ? Leisure and sports ? Weather forecast ? Vertical velocity indication (rise/sink speed)

Mini Infrared Detector Module

105 Per Piece

• Output level: High 3.3V / Low 0V
• Trigger: repeatable trigger (default)
• Automatic induction: to enter the sensing range of the output is high, people leave the sensor range automatically delay off high, output low. Ultra-small size.
• Repeatable trigger: the sensor output high, the delay period, if there is human activity in its sensing range, the output will remain high until people leave after the high variable delay Low (automatically extended sensor module detects the human body after every activity a
• Wide operating voltage range: the default operating voltage DC4.5V-20V.
• Micropower: quiescent current <50 microamps, especially for battery-powered automatic control products.
• Output high signal: easy docking and all kinds of circuits.
• Model:: HC-SR505
• Operating Voltage Range:: DC4.5-20V
• Average Current Consumption (mA):: 0.06
• Distance Measuring Range:: 3 meters
• Dimensions (mm) LxWxH:: 10 x 23 x 5
• Weight (gm):: 10
• Delay time:: Default 8S + -30% (can be customized)
• Working Temperature Range:: -20°C
• Sensor Lens Diameter:: 10mm
• Induction angle:: <100-degree cone angle
