Printer Control Card
Get Price Quote
We are instrumental in manufacturing and supplying of printer control card that can be easily installed in all brands of printers. Our printer control cards are available in different specifications. These printer control cards are well-acclaimed for their superior quality and easy availability among the clients.
appreciated for
high performanceeasy installationlonger service lifehigh quality
»specifications
size53(w) × 73(l) × 20(h) mmdata inputrs232c serial or ttlcontrol functionspaper feed and self testpower supply+5vdc, 200ma when not printing & 2a (average) when printing, peak current 4a.character set96 characters ascii (as shown below) : ! " £ $ % & ' ( ) * + , - . / 0 1 2 3 4 5 6 7 8 9 : ; < = > ? @ a b c d e f g h I j k l m n o p q r s t u v w x y z [ ] ^ _ ` a b c d e f g h I j k l m n o p q r s t u v w x y z ° # ~no. Of columns24 in normal modeprinting speed2.7 lps ±20% (typical)(5 -7 font + 3-dot line spacing)coping capability1 original + 1 copyconnectors20 pins relimate for mechanism7 pins relimate for power and serial data.4 pins relimate for control signals.jumpers3+3 jumper for rs232c and ttl selection2+2 jumper for baud ratetemperature0 to +50o chumidity0 to 90% rh (non condensing)
