Rigid UPVC Pipes
Get Price Quote
rigid Upvc Pipes Offered By Us, are Made of High-grade Resin Which Ensures the Fulfillment of the Basic Need for Clean and Hygienic Water. They are Made On the Latest, State-of-the-art Plants in India. Our Pipes have a Long Service Life of More Than 50 Years and are Maintenance Free. They are Highly Corrosion Resistant, Chemical and Biological Resistant. the Rigid Upvc Pipes Can Accommodate Slight Shifting of the Soil, Bending of the Pipe Up to 2 Degrees per Joint and Tolerate Small Gradients in Underground Piping. Seal Rings Help in Easy Installation. Our Upvc Pipes Can Be Tested for Ability to Withstand Pressure Immediately On Completion of Installation. There is No Need to Wait for the Joints to Dry, Etc.
variations Available
plain Pipes : Supplied with One Coupler for Solvent Cement Joining as per Lay & Joining Standards.socketed Pipes : have One End Self-socketed and other End Plain. It Joins with the Help of Solvent Cementelastomeric Ring Fit Pipes : It Comes with Electrometric Sealing Ring Which Enhances the Upvc System Joining, Especially in Higher Diameter Pipes from 140mm - 400mm Od. Rubber Sealing Rings Ensures the Leak Proof Joints and Easy Installation. It Can Withstand the Pressure Beyond the Specified Testing Pressure for Pipes
these Pipes are Branded , and Manufactured as per is 4985: 2000.
application Areas
irrigation Schemetube Wellbio Gas Plantrainwater
drinking Water Supply Linesmain Line for Sprinklers / Drip Irrigationunderground or Open Pipelinetelecommunication Cable Ducting
directions for Use
minimum Depth of Engagement
installation : Using Simple Joining Equipment, Upvc Firm Seal Pipes Can Be Installed with Extreme Convenience and Speed Essential in the Case of Large Diameter.
position of Sealing Ring : the Sealing Ring Has to Be Inserted in the Groove of the Socket Property. Please Ensure Ring is Correctly Positioned with Its Thickest Edge Inner Most.
the Temperature Variation Advantage in Addition to the Advantage of Convenience, Upvc Firm Seal Pipe is Better Able to Withstand Leaks Caused By Temperature Variation.
for Plain/socketed Pipes
the Method of Joining Generally Recommended are :
pvc Solvent Joining, Flange Joining, Rubber Ring Joining & Threaded Joining. Pvc Solvent Cement Joining Gives Good Result for all the Sizes and Should Be Executed as Follows :inspect the Pipe and Fittings to Ensure that They Match Perfectlycut the Pipe Square Using a Hacksaw Then Remove Burr & Even Surface Using a Fliersandpaper the Outside and Inside of Fittings, Wipe Clean Using a Clean Brushapply Solvent Cement Evenly Not More Not Less with Soft Brush On the Outside of Pipe and Inside of the Fittingsinsert the Pipe in the Fitting and Turn It Through 180o to Ensure Even Distribution of Pvc Solvent Cementhold the Joint for 2 Minutes and Ensure Pipe Does Not Slip Out of Fittingwipe and Clean the Express Pvc Solvent Cement from Entire Surface of Joint and Keep Undisturbed for At Least 30 Minutes
Firmseal
a Six Step Simple, Easy, Convenient and Speedy Process
clean Inside of Pipe Socket and Groove for Firmsealslightly Wet Firmseal and Squeeze Into Heart Shape, Position It Inside the Pipe Socket for It to Snap. (the Socket is a 15o Chamfer Provides in the Pipe.)clean the Pipe Ends and Coat It with Rubber Lubricant Before Pushing Into the Socket. Mark Insertion Depth if Not Already Providedpush Together Only Up to the Insertion Mark to Take Care of Expansion. for Large Diameter Pipe, a Pipe Jack May Be Usedif Shorter Lengths are Required Cut Off the Pipe Ends Squarely Using a fine Toothed Saw and Miter Boxbefore Inserting the Cutoff Pipe in the Socket, Its End Must Be Deburred and Chamfered Approx 15o
