Industrial Furnace Dealers in Chetpet, Chennai

Induction Furnace has coil constructed from heavy copper tubing. It is designed and tuned to the inverter circuit which applies a medium frequency (generally 500 Hz or 1000 Hz) voltage to the Induction coil. The magnetic field produced by the induction coil induces eddy currents in the charge and heats it. Medium frequency is necessary to enhance the rate of heat generation.The inverter circuit requires for its operation a D.C. Voltage which is obtained by converting available three phase A.C. Voltage. Transformers which are used for transforming available three phase A.C. voltage to required voltage for converter circuit of the Induction Furnace are referred to as Induction Furnace Transformers. Thus they are essentially Rectifier Converter Duty Transformers.

Kiln Burner, Classifiers, Cyclones, Roll Press Part

5e-mf6100k muffle furnace is used to determine the ash, volatile matter in coal, coke, biomass and other organic material. Over-temp alarm and scmpc temperature control. One pc connects more than one muffle furnace. Available to record and transmit analysis data for each set, including sample number, sample mass, heating time, results.

This is for maximum temp. up to 1000’C/1200’C and recommended regular working temperature not to exceed 930’C/110’C. Accuracy +/-5’C.Construction:The furnace has a sillimanite muffle/Refractory grooved chamber with a smooth internal surface. Imported “Kanthal A1” heating elements will be provided all around the heating chamber packed by good graded insulation. Ceramic Fibre work will be provided on all of the chamber to minimize heat less due to radiation. An over-heat cut-off fuse is provided is preventing the heating elements against accidental heating.The furnace outer frame is fabricated from mild steel sheets and sections is finished with an attractive duco paint/powder coated paint. The furnace has a simple flap type of door with a spy hole for viewing the chamber.Control Gear:Consists of Energy Regulator, Pyrometer with Chrome/Alumel thermocouple, Two indicating lamps, etc., which will be mounted on top of the furnace itself. The furnace will be supplied complete with 2 meters of 3 core wire with 3 pin plug for operation on 220/230 volts, single phase, 50 c/s, AC mains. Optional: (The above equipment can be fitted with following accessories on extra cost)    1. Digital Temp. Indicating cum Controller with P.D. Action for best accuracy +/-1’C with Ammeter and indicator On/Off switch “Instead” of pyrometer and Energy Regulator.    2. Digital Temperature indicator.    3. Automatic Blind Controller.    4. Automatic Digital Timer for 999 mins./999 hrs.

  SALIENT FEATURES PID temperature controller Cold rolling steel spraying exterior Elements embedded in walls of the chamber to provide, high temperature, uniform heating and long service life Light-weight insulating brick, fiber cotton are used as thermal insulation material to ensure good heat insulation, to promote heat storage capacity, to shorten heating up time, and to reduce power loss and power consumption.

Oil Crematoriums, Piping, Utility Piping Service, Steam Piping Servic

Clinker Cooler, Pan Conveyo

Induction Furnace, Induction Melting Furnace, Induction Heater

Industrial Furnac

Gold Melting Machine, Cash Counting Machine, Fake Note Detector Machin

Electric Furnaces, Bod Incubators, Electric Ovens, Hot Driers Incubator

Melting Furnaces, Weighing Scale, Gold Refining Machine, Gold Smith Tool
