Addressable Intelligent multisensor
Features : Soft addressing Pre alarm Contamination alarm Remote test facility from the panel
Quiescent current : : 200uA
Thermal sensitivity : : 57ºC
This Addressable Intelligent Multisensor is a networkable instrument that houses smoke and thermal sensors for monitoring the level of smoke & heat in its surveillance. Its unique feature is to provide the live temperature and smoke level to the control panel for real time monitoring purpose. This detector with a unique ID communicates to the control panel by pin pointing its exact location.
Multi Sensor Smoke Detector
Operating Voltage : 17 – 41Vd.c.,
Low Power Mode (typ) : 12m A,
Quiescent Current (typ) : 39m A,
Alarm Current (CONTROLLED BY CIE) : 19mA,
Transmission Method : Digital Communications Using ESP,
Operating Temperature Range : –10°C to +50°C,
Storage Temperature Range : –30°C to +60°C,
Maximum Humidity : 95%RH - Non- Condensing (at 40°C),
Ingress Protection Rating : Ip67,
Colour / Case Material : Ivory White / Polycarbonate,
Weight (g) : 100.
Diameter (MM) / Height With Base (MM) : 100 / 46,
Compatible Bases : CF-YBN-R/3, CF-YBO-BS, CF-YBO-BSB, CF-YBO-R/SCI,
Base Fixing Centres (MM) : 48 - 74
