Modular and scalable, VersaMax offers big PLC power in a small package. It is part of an innovative control family that combines a powerful CPU with a broad selection of discrete, analog, mixed and specialty I/O modules, terminations and power supplies, as well as ommunications modules to link to a variety of networks.

The Selec MFM383 Electrical Panel Meters is a Multifunction Meters which can indicate voltage, current, power, power factor, frequency and energy in operation of equipment, machinery, systems or processes in a wide range of industrial applications. It consists of LCD (with Backlight) 3 rows of 3 digits, Bar graph, 8 digits for energy. Comprises of Input type: 3ø-4 wire and 1ø supply, 5A max and a Programmable CT PT primary and secondary. Supply Voltage: 85 to 270V ACDC (5060 Hz). RS485 MODBUS Communication Version also available.

Country of Origin : 85-270VAC

Display Type : LED

Frequency : 50 Hz

Brand Name : Selec

Size : 48x48mm

Accuracy : For TC (J, K, T) inputs: 0.25% of F.S. +-1 For R & S inputs: 0.5% of F.S. +-2 (20min of warm up time)

Display Type : 7 Segment LED Dual Display

Mounting Type : Panel Mount

Frequency : 50 Hz

Material : Mild Steel

Feature : Single step ramp soak

The Selec XT242 is a dual line display 4 digit multifunction LED digital timer and a multi-time range digital timer with push buttons suitable for controlling operation of equipment, machinery, systems or processes in a wide range of industrial applications. Four timing functions can be selected together with time ranges from 0.01 to 9999hr and operates on different modes like Multifunction: On delay, Interval, Cyclic ON first, Cyclic OFF first with optional , to operate single independent relay output contact which are isolated from the supply voltage. The output contacts can be configured as single timed outputs, or one timed and one instantaneous output. These timers are housed in a compact panel mounting enclosure and are powered from 85 to 270Vacdc.

The Selec TC544 is a sophisticated auto tuning PID controller or on/off controller with selectable thermocouple, RTD up to two outputs. Versions are available with different relay and SSR outputs. The controller can be configured as on/off or PID control and alarm outputs, or as 2 on/off or PID controls (heat/cool) plus 1 alarm output. It has a large dual 4 digit LED display to show the set point and the process value and is suitable for use with power supplies of 85 to 270 VAC.     Features Dual display, 4 digit, 7 segment LED TC / RTD input PID, ON/OFF control Two set points °C / °F selectable Field selectable control output (Relay or SSR) Auxiliary output: Relay Easy to use

The Selec TC52 is a sophisticated Analog Temperature controller or on/off controller with Thermocouple inputs and one Relay output. The controller is configured as on/off control and easy to use with a Dial to set the desired set point and is suitable for use with power supplies of 85 to 270 VAC.     Features J/K Type TC input ON-OFF & Proportional control Single relay output Easy to use

The Selec TC518 is a sophisticated auto tuning PID controller or on/off controller with selectable thermocouple, RTD up to two outputs. Versions are available with different relay and SSR outputs. The controller can be configured as on/off or PID control and alarm outputs, or as 2 on/off or PID controls (heat/cool) plus 1 alarm output. It has a large dual 3 digit LED display to show the set point and the process value and is suitable for use with power supplies of 85 to 270 VAC   Features High performance Dual display, 4 digit, 7 segment LED LED status indicator: Relay ON, Tune 3 front panel control buttons TC / RTD inputs PID, ON/OFF control Single set point °C / °F selectable Control output: Relay or SSR drive

The Selec TC513 is a sophisticated auto tuning PID controller or on/off controller with selectable thermocouple, RTD up to two outputs. Versions are available with different relay and SSR outputs. The controller can be configured as on/off or PID control and alarm outputs, or as 2 on/off or PID controls (heat/cool) plus 1 alarm output. It has a large dual 3 digit LED display to show the set point and the process value and is suitable for use with power supplies of 85 to 270 VAC Features Single display, 3 digit, 7 segment LED TC / RTD inputs PID, ON/OFF control Single set point °C / °F selectable Field selectable control output (Relay or SSR) Easy to use

The Selec TC344 is a sophisticated auto tuning PID controller or on/off controller with selectable thermocouple, RTD up to two outputs. Versions are available with different relay and SSR outputs. The controller can be configured as on/off or PID control and alarm outputs, or as 2 on/off or PID controls (heat/cool) plus 1 alarm output. It has a large dual 4 digit LED display to show the set point and the process value and is suitable for use with power supplies of 85 to 270V AC.   Features Dual display, 4 digit, 7 segment LED TC / RTD input PID, ON/OFF control Two set points °C / °F selectable Field selectable control output (Relay or SSR) Auxiliary output: Relay Easy to use

The Selec TC303 is a sophisticated auto tuning PID controller or on/off controller with selectable thermocouple, RTD up to two outputs. Versions are available with different relay and SSR outputs. The controller can be configured as on/off or PID control and alarm outputs, or as 2 on/off or PID controls (heat/cool) plus 1 alarm output. It has a large dual 3 digit LED display to show the set point and the process value and is suitable for use with power supplies of 85 to 270V AC     Features   Single display, 3 digit, 7 segment LED TC / RTD inputs PID, ON/OFF control Single set point °C / °F selectable Field selectable control output (Relay or SSR) Easy to use

The Selec TC244 is a sophisticated auto tuning PID controller or on/off controller with selectable thermocouple, RTD up to two outputs. Versions are available with different relay and SSR outputs. The controller can be configured as on/off or PID control and alarm outputs, or as 2 on/off or PID controls (heat/cool) plus 1 alarm output. It has a large dual 4 digit LED display to show the set point and the process value and is suitable for use with power supplies of 85 to 270 VAC.   Features Dual display, 4 digit, 7 segment LED TC / RTD input PID, ON/OFF control Two set points °C / °F selectable Field selectable control output (Relay or SSR) Auxiliary output: Relay Easy to use

The Selec TC203 is a sophisticated auto tuning PID controller or on/off controller with selectable thermocouple, RTD up to two outputs. Versions are available with different relay and SSR outputs. The controller can be configured as on/off or PID control and alarm outputs, or as 2 on/off or PID controls (heat/cool) plus 1 alarm output. It has a large dual 3 digit LED display to show the set point and the process value and is suitable for use with power supplies of 85 to 270 VAC   Features Single display, 3 digit, 7 segment LED TC / RTD inputs PID, ON/OFF control Single set point °C / °F selectable Field selectable control output (Relay or SSR) Easy to use

The Selec RC5100 is a 4 digit Rate/RPM Indicators indicator and 4 digit counter suitable for RPS/RPM/RPH indications and counting in operation of equipment, machinery, systems or processes in a wide range of industrial applications. The controllers accepts input from - Proximity switches, Encoders, Potential free contacts, with input speed from 4 to 9999 pulses per minute. These RPM indicators are housed in a compact panel mounting enclosure and are powered from 85 to 270V AC/DC.   Features   Inbuilt sensor supply Measures upto 9999 RPM

The Selec RC5100 is a 4 digit Rate/RPM Indicators indicator and 4 digit counter suitable for RPS/RPM/RPH indications and counting in operation of equipment, machinery, systems or processes in a wide range of industrial applications. The controllers accepts input from - Proximity switches, Encoders, Potential free contacts, with input speed from 4 to 9999 pulses per minute. These RPM indicators are housed in a compact panel mounting enclosure and are powered from 85 to 270V AC/DC.   Features Inbuilt sensor supply Measures upto 9999 RPM

The Selec RC2106 is a 4 digit Rate/RPM Indicators indicator suitable for PS/RPM/RPH indications in operation of equipment, machinery, systems or processes in a wide range of industrial applications. The controllers accepts input from - Proximity switches, Encoders, Potential free contacts, with input speed from 0 to 3.5 KHZ and 4.00 RPM to 9999 RPM. These RPM indicators are housed in a compact panel mounting enclosure and are powered from 85 to 270V AC/DC.   Features Auto ranging RPM indicator Scalable input Measures upto 9999 RPM Input speed upto 3.5KHz

The Selec RC2106 is a 4 digit Rate/RPM Indicators indicator suitable for PS/RPM/RPH indications in operation of equipment, machinery, systems or processes in a wide range of industrial applications. The controllers accepts input from - Proximity switches, Encoders, Potential free contacts, with input speed from 0 to 3.5 KHZ and 4.00 RPM to 9999 RPM. These RPM indicators are housed in a compact panel mounting enclosure and are powered from 85 to 270V AC/DC.   Features Auto ranging RPM indicator Scalable input Measures upto 9999 RPM Input speed upto 3.5KHz

The Selec RC2100 is a 4 digit Rate/RPM Indicators indicator and 4 digit counter suitable for RPS/RPM/RPH indications and counting in operation of equipment, machinery, systems or processes in a wide range of industrial applications. The controllers accepts input from - Proximity switches, Encoders, Potential free contacts, with input speed from 4 to 9999 pulses per minute. These RPM indicators are housed in a compact panel mounting enclosure and are powered from 85 to 270V AC/DC. Features Inbuilt sensor supply Measures upto 9999 RPM

The Selec XC1200 is a 6 digit Counter with push wheel setting suitable for counting operation of equipment, machinery, systems or processes in a wide range of industrial applications. It has following operating modes on-delay, Interval delay, auto reset, time pulse repeat. Accepts input from - Proximity switches, Encoders, Potential free contacts with optional 10 years memory retention, with input speed from 0 to 5 KHZ and 9999 counts and 4.00 RPM/RPH to 99999 RPM/RPH and to operate two independent relay output contacts with two set point which are isolated from the supply voltage. These counters are housed in a compact panel mounting enclosure and are powered from 85 to 270V AC/DC.           Features 5 digits RPM indicator, 6 digts counter LED status indicator: Relay 1, Relay 2 2 setpoints Programmable input scaling Up, Down, Quadrature & Bi-directional

The Selec XC200NX is a 6 digit Counter with push wheel setting suitable for counting operation of equipment, machinery, systems or processes in a wide range of industrial applications. It has following operating modes on-delay, Interval delay, auto reset, time pulse repeat. Accepts input from - Proximity switches, Encoders, Potential free contacts with optional 10 years memory retention, with input speed from 0 to 5 KHZ and 9999 counts and 4.00 RPM/RPH to 99999 RPM/RPH and to operate two independent relay output contacts with two set point which are isolated from the supply voltage. These counters are housed in a compact panel mounting enclosure and are powered from 85 to 270V AC/DC.   Features 5 digits RPM indicator, 6 digts counter LED status indicator: Relay 1, Relay 2 2 setpoints Programmable input scaling Up, Down, Quadrature & Bi-directional

The Selec RC2108 is a 4 digit Rate/RPM Indicators indicator suitable for PS/RPM/RPH indications and alarms in operation of equipment, machinery, systems or processes in a wide range of industrial applications. The controllers accepts input from - Proximity switches, Encoders, Potential free contacts with optional 10 years memory retention, with input speed from 0 to 3.5 KHZ and 4.00 RPM to 9999 RPM and to operate two independent relay output contacts (high and low alarm)with two set point which are isolated from the supply voltage. These RPM indicators are housed in a compact panel mounting enclosure and are powered from 85 to 270V AC/DC.   Features RPS, RPM, RPH indicator Scalable input High & Low alarm Programmable alarm delay

The Selec XC410 is a 6 digit Counter with push buttons suitable for counting operation of equipment, machinery, systems or processes in a wide range of industrial applications. Accepts input from - Proximity switches, Encoders, Potential free contacts with optional 10 years memory retention, with input speed from 0 to 1 KHZ and 999999 counts. These counters are housed in a compact panel mounting enclosure and are powered from 90 to 270Vac/dc.   Features 6 digits, 7 segments LED totaliser Compact size Inbuilt sensor supply

The Selec LXC 900 counter is a 8 digit LCD timer with self powered battery and backlight suitable for counting operation of equipment, machinery, systems or processes in a wide range of industrial applications. 8 digit counting, to operate with contact input or voltage input. These counters are housed in a compact panel mounting enclosure and are powered from 24 to 260Vac/dc.   Features 8 digit LCD counter Self powered Long battery life Contact / Voltage input
