In vacuum die casting the mould/die is kept at vacuum condition (10-2 mbar) to remove the gases from the melt. In Bottom Pouring Type Stir Casting machine this is made more efficient by introducing the mould/die in high vacuum conditions immediatly once the melt is flown filled into the die/mould. No manual operation is required for the above process.   Vacuum Pump: Double Stage Vacuum Tank & Chamber: Made of Stainless Steel Vacuum indication: Dial type guage fitted in the control panel Die/Mould: Split type to obtain a cast of 50 mm OD x 300mm Long (Standard) Any other split type die/mould can be manufactured as per the user's requirement

We are the main supplier of this product.

Types Available: Standard or Tilting Type  Door Types: Horizontal (Front opening) or Vertical (Swirling type top opening) Temperature Ranges: 1000, 1400, 1600 or > 1800 till 3000 deg.C Working Dimensions: Chamber volume from 10 liters to 1000 liters (As per customer’s requirement) Heating Chamber: Stainless steel,  mullite, alumina and high alumina refractory (as per the temperature requirement) Heating Type: Standard or Rapid Heating (Kanthal A1, Kanthal APM, Silicon carbide, molybdenum disilicide and graphite) Atmospheric Control: Vacuum (Upto 10 -6 mbar), Oxidizing (normal) & inert with Argon, CO2, Nitrogen and Hydrogen Temperature Control: Electronic PID based ON/OFF or Programmable controllers with data acquisition system (As per customer's requirement) Safety Features: Broken Thermocouple & temperature overshoot protection. Scale Availability: Industrial & Laboratory

Power : 230VAC supply

Power Consumption : 20 KW @ 400/440 VAC, 3 Phase, 50 Hz
