Water Treatment Plant Dealers in Thirumudivakkam, Chennai

Lamella Clarifier is primarily used in the water and wastewater treatment industries to separate solids from liquids in effluent streams. The clarifier is the third step in what is usually a four step process for water and wastewater treatment. In wastewater treatment the four main steps are collection and homogenization of effluent, pH adjustment, clarification and sludge dewatering.Conventional clarification equipment requires a much larger surface footprint in order to match the solids removal capacity of a Lamella Clarifier. This is accomplished because the effective gravity settling area of the inclined plate design is proportional to the total surface area of the inclined plate rack. Loading rates normally used for the design of conventional settlers can be applied to the sizing of a Lamella clarifier or settler by substituting projected area for the surface settling area of a conventional clarifier.The compact design of this Lamella Clarifier essentially eliminates any hydraulic disturbances caused by wind or temperature changes that may be problematic with conventional clarifiers located outdoors. Balanced flow distribution ensures equal flow to each plate and across the plate surface area, preventing short-circuiting. Units and plate packs arrive at the job site factory assembled which reduces installation time while cutting down the installation costs. Minimal moving parts mean low maintenance costs.Operating Principle : Our Lamella Clarifier with a series of inclined plates are arranged to form a separate sedimentation chamber between adjacent plates. Raw water is first fed to Static Mixer and chemicals such as alum, poly electrolyte are added prior to static mixer for proper mixing of chemicals in water. Water from static mixer enters in Flocculator in which paddle type agitator is provided for gentle mixing. Polymer is added for flocculation of coagulated particles.

We are widely appreciated for offering precision engineered Domestic Reverse Osmosis System. Our Domestic Reverse Osmosis System is highly demanded in the cleaning of water to be used for drinking and other purposes. These Domestic Reverse Osmosis Systems are fitted with tested components to offer perfection in the water cleaning process. These Domestic Reverse Osmosis Systems are easy to operate and remain in use for years. Attributes Easy to operateHigh-end featuresLow maintenance requiredHigh performance

The demineralization is the process of removing mineral salts from water by using ion exchange process. The D.M water reduces the scale formation, Deposition and corrosion of tubes. It increases the life of pipes and tubes in plant. It prevents the deposition of minerals in turbine blades. It removes Mineral salts in the form of cations such as sodium, calcium, iron, copper and anions such as chloride, sulphate , nitrate etc.   MIXED BED UNITS:-   After passing water through cation then anion exchanger it is passed through mixed bed unit. In mixed bed cation and anion resins are mixed and while water passes through it as it passes through thousands of cation/anions exchanger ‘resulting final effluent of very good quality water.     Application   Pharmaceutical industry Boiler industry Sterilization industry

Features High Quality Water :Our reverse osmosis not only rejects most organics and salts from water but residual synthetic detergents, bacteria, viruses and suspended microscopic particles.System Includes 4" & 8" Composite Polymer High Flow Membranes Pretreatment – Sand/Carbon/Softener* Posttreatment – Demineralization/EDI Control Panel with PLC Feed & High Pressure Pumps Cartridge/ Bag Filters Pressure Monitors Flow Monitors Feed/ Booster Pumps Chemical Dosing Pumps Pressure Switches Conductivity/Level Controller S.S./ M.S. Powder Coated Frame Std PVC/ PVC-U/ S.S. Piping Operating Specifications Configuration: Spiral Wound Membranes Operating Process: Single Stage/Recycling/Openflow Recovery :Upto 60% Operating Temperature :< 40 C Operating Pressure: 8 – 15 Bar Flow Rate: Upto 25 M3/Hr Product Turbidity: ≤ 0.1 NTU
